STM8S105xx
Access line, 16 MHz STM8S 8-bit MCU, up to 32 Kbytes Flash,
integrated EEPROM,10-bit ADC, timers, UART, SPI, I²C
LQFP48 7x7
LQFP44 10x10
LQFP32 7x7
VFQFPN32 5x5
SDIP32 400 ml
UFQFPN32 5x5
Features
Core
•
16 MHz advanced STM8 core with Harvard
architecture and 3-stage pipeline
•
Extended instruction set
Memories
•
Medium-density Flash/EEPROM:
-
Program memory up to 32 Kbytes; data
retention 20 years at 55°C after 10 kcycles
-
Data memory up to 1 Kbytes true data
EEPROM; endurance 300 kcycles
•
RAM: Up to 2 Kbytes
Clock, reset and supply management
•
2.95 V to 5.5 V operating voltage
•
Flexible clock control, 4 master clock sources:
-
Low power crystal resonator oscillator
-
External clock input
-
Internal, user-trimmable 16 MHz RC
-
Internal low power 128 kHz RC
•
Clock security system with clock monitor
•
Power management:
-
Low power modes (wait, active-halt, halt)
-
Switch-off peripheral clocks individually
•
Permanently active, low consumption power-on
and power-down reset
Interrupt management
•
Nested interrupt controller with 32 interrupts
•
Up to 37 external interrupts on 6 vectors
Timers
•
2x 16-bit general purpose timers, with 2+3
CAPCOM channels (IC, OC or PWM)
•
Advanced control timer: 16-bit, 4 CAPCOM
channels, 3 complementary outputs, dead-time
insertion and flexible synchronization
•
8-bit basic timer with 8-bit prescaler
•
Auto wake-up timer
•
Window and independent watchdog timers
Communications interfaces
•
UART with clock output for synchronous
operation, Smartcard, IrDA, LIN
•
SPI interface up to 8 Mbit/s
•
I
2
C interface up to 400 Kbit/s
Analog-to-digital converter (ADC)
•
10-bit, ±1 LSB ADC with up to 10 multiplexed
channels, scan mode and analog watchdog
I/Os
•
Up to 38 I/Os on a 48-pin package including 16
high sink outputs
•
Highly robust I/O design, immune against current
injection
Development support
•
Embedded single wire interface module (SWIM)
for fast on-chip programming and non intrusive
debugging
Unique ID
•
96-bit unique key for each device
Table 1: Device summary
Part numberReference
STM8S105K4, STM8S105K6, STM8S105S4, STM8S105S6,
STM8S105C4, STM8S105C6
STM8S105xx
1/127
DocID14771 Rev 9
April 2010
www.st.com
