TC75S101F/FU/FE
2011-04-22
2
Marking
(top view)
Pin
Connection
(top view)
Electrical Characteristics
DC Characteristics
(V
DD
= 3.0 V, V
SS
= GND, Ta = 25°C)
Characteristics Symbol Test Condition Min Typ. Max Unit
Input offset voltage V
IO
R
S
= 1Ω, R
F
= 100 kΩ ― 1.2 3.0 mV
Input offset current I
IO
― ― 0.1 ― pA
Input bias current I
I
― ― 0.1 ― pA
Common mode input voltage CMV
IN
R
S
= 1Ω, R
F
= 100 kΩ 0 ― 3.0 V
Voltage gain (open loop) G
V
― 40 110 ― dB
V
OH
R
L
100 kΩ 2.9 ― ―
Maximum output voltage
V
OL
R
L
100 kΩ ― ― 0.1
V
Common mode input signal
rejection ratio
CMRR V
IN
= 0.0 to 3.0 V 50 66 ― dB
Supply voltage rejection ratio SVRR V
DD
= 1.8 to 6.0 V 65 90 ― dB
Supply current I
DD
― ― 63 90 μA
Source current Isource
―
70 110 ― μA
Sink current Isink
―
800 1500 ― μA
DC Characteristics
(V
DD
= 1.8 V, V
SS
= GND, Ta = 25°C)
Characteristics Symbol Test Condition Min Typ. Max Unit
Input offset voltage V
IO
R
S
= 1Ω, R
F
= 100 kΩ ― 0.9 3.0 mV
Input offset current I
IO
― ― 0.1 ― pA
Input bias current I
I
― ― 0.1 ― pA
Common mode input voltage CMV
IN
R
S
= 1Ω, R
F
= 100 kΩ 0 ― 1.8 V
Voltage gain (open loop) G
V
― 40 100 ― dB
V
OH
R
L
100 kΩ 1.7 ― ―
Maximum output voltage
V
OL
R
L
100 kΩ ― ― 0.1
V
Supply current I
DD
― ― 57 80 μA
Source current Isource
―
50 95 ― μA
Sink current Isink
―
700 1450 ― μA
V
DD
5
IN (−)
4
1 3
V
SS
2
OUT
IN (+)
S J
