©2005 Fairchild Semiconductor Corporation www.fairchildsemi.com
TIL111M, TIL117M, MOC8100M Rev. 1.0.3 2
TIL111M, TIL117M, MOC8100M — General Purpose 6-Pin Phototransistor Optocouplers
Safety and Insulation Ratings
As per IEC60747-5-2. This optocoupler is suitable for “safe electrical insulation” only within the safety limit data.
Compliance with the safety ratings shall be ensured by means of protective circuits.
Symbol Parameter Min. Typ. Max. Unit
Installation Classifications per DIN VDE 0110/1.89 Table 1
For Rated Mains Voltage < 150 V
RMS
I–IV
For Rated Mains Voltage < 300 V
RMS
I–IV
Climatic Classification 55/100/21
Pollution Degree (DIN VDE 0110/1.89) 2
CTI Comparative Tracking Index 175
V
PR
Input to Output Test Voltage, Method b,
V
IORM
x 1.875 = V
PR
, 100% Production Test with
t
m
= 1 s, Partial Discharge < 5 pC
1594
Input to Output Test Voltage, Method a,
V
IORM
x 1.5 = V
PR
, Type and Sample Test with
t
m
= 60 s, Partial Discharge < 5 pC
1275
V
IORM
Maximum Working Insulation Voltage 850 V
peak
V
IOTM
Highest Allowable Over Voltage 6000 V
peak
External Creepage 7 mm
External Clearance 7 mm
Insulation Thickness 0.5 mm
R
IO
Insulation Resistance at T
S
, V
IO
= 500 V 10
9
Ω
