GND Line
Connector
(Source of ESD)
ESD Sensitive Device
1 1
22
IO Line 1
IO Line 2
Product
Folder
Sample &
Buy
Technical
Documents
Tools &
Software
Support &
Community
TPD1E10B06
SLLSEB1D FEBRUARY 2012REVISED NOVEMBER 2015
TPD1E10B06 Single-Channel ESD Protection Diode in 0402 Package
1 Features 3 Description
The TPD1E10B06 device is a single-channel
1
Provides System-Level ESD Protection for Low-
electrostatic discharge (ESD) transient voltage
Voltage I/O Interface
suppression (TVS) diode in a small 0402 package.
IEC 61000-4-2 Level 4 ESD Protection
This TVS protection product offers ±30-kV contact
±30 kV Contact Discharge
ESD, ±30-kV IEC air-gap protection, and has an ESD
clamp circuit with a back-to-back TVS diode for
±30 kV Air-Gap Discharge
bipolar or bidirectional signal support. The 12-pF line
IEC 61000-4-5 Surge: 6 A (8/20 µs)
capacitance of this ESD protection diode is suitable
I/O Capacitance 12 pF (Typical)
for a wide range of applications supporting data rates
up to 400 Mbps. The 0402 package is an industry
R
DYN
0.4 Ω (Typical)
standard and is convenient for component placement
DC Breakdown Voltage ±6 V (Minimum)
in space-saving applications.
Ultralow Leakage Current 100 nA (Maximum)
Typical applications of this ESD protection product
10-V Clamping Voltage (Max at I
PP
= 1 A)
are circuit protection for audio lines (microphone,
Industrial Temperature Range: –40°C to 125°C
earphone, and speakerphone), SD interfacing,
keypad or other buttons, VBUS pin and ID pin of USB
Space-Saving 0402 Footprint
ports, and general-purpose I/O ports. This ESD clamp
(1 mm × 0.6 mm × 0.5 mm)
is good for the protection of the end equipment like
ebooks, tablets, remote controllers, wearables, set-
2 Applications
top boxes, and electronic point of sale equipment.
End Equipment:
Device Information
(1)
Tablets
PART NUMBER PACKAGE BODY SIZE (NOM)
Remote Controllers
TPD1E10B06 X1SON (2) 0.60 mm × 1.00 mm
Wearables
(1) For all available packages, see the orderable addendum at
Set-Top Boxes
the end of the data sheet.
Electronic Point of Sale (EPOS)
ebooks
Interfaces:
Audio Lines
Pushbuttons
General-Purpose Input/Output (GPIO)
Application Schematic
1
An IMPORTANT NOTICE at the end of this data sheet addresses availability, warranty, changes, use in safety-critical applications,
intellectual property matters and other important disclaimers. PRODUCTION DATA.
