SBAS417B − JUNE 2007 − REVISED JANUARY 2008
www.ti.com
2
ABSOLUTE MAXIMUM RATINGS
(1)
+V
CC
and IOVDD to GND −0.3V to +6V. . . . . . . . . . . . . . . . . . . . .
Analog Inputs to GND −0.3V to +V
CC
+ 0.3V. . . . . . . . . . . . . . . . .
Digital Inputs to GND −0.3V to IOVDD + 0.3V. . . . . . . . . . . . . . . . .
Power Dissipation 250mW. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maximum Junction Temperature +150°C. . . . . . . . . . . . . . . . . . . . . .
Operating Temperature Range −40°C to +85°C. . . . . . . . . . . . . . . .
Storage Temperature Range −65°C to +150°C. . . . . . . . . . . . . . . . .
Lead Temperature (soldering, 10s) +300°C. . . . . . . . . . . . . . . . . . . . .
IEC Contact Discharge (X+, X−, Y+, Y−)
(2)
±15kV. . . . . . . . . . . . . . .
(1)
Stresses above these ratings may cause permanent damage.
Exposure to absolute maximum conditions for extended periods
may degrade device reliability. These are stress ratings only, and
functional operation of the device at these or any other conditions
beyond those specified is not implied.
(2)
Test method based on IEC standard 61000−4−2. Contact Texas
Instruments for test details.
ELECTROSTATIC DISCHARGE SENSITIVITY
This integrated circuit can be damaged by ESD. Texas
Instruments recommends that all integrated circuits be
handled with appropriate precautions. Failure to observe
proper handling and installation procedures can cause damage.
ESD damage can range from subtle performance degradation to
complete device failure. Precision integrated circuits may be more
susceptible to damage because very small parametric changes could
cause the device not to meet its published specifications.
PACKAGE/ORDERING INFORMATION
(1)
PRODUCT
NOMINAL
PENIRQ
PULLUP
RESISTOR
VALUES
MAXIMUM
INTEGRAL
LINEARITY
ERROR
(LSB)
PACKAGE-
LEAD
PACKAGE
DESIGNATOR
SPECIFIED
TEMPERATURE
RANGE
PACKAGE
MARKING
ORDERING
NUMBER
TRANSPORT
MEDIA, QUANTITY
TSSOP-16
PW
−40°C to +85°C
TSC2046EI
TSC2046EIPW Rails, 100
TSSOP-16 PW −40°C to +85°C TSC2046E
I
TSC2046EIPWR Tape and Reel, 2500
TSC2046E
50kΩ
±2
4x4, 0.8mm
Thin
RGV
−40°C to +85°C
TSC2046E
TSC2046EIRGVT Tape and Reel, 250
TSC2046E
50kΩ
±
2
Thin
QFN-16
RGV −40°C to +85°C TSC2046E
TSC2046EIRGVR Tape and Reel, 2500
4x4
VFBGA-48
ZQC −40°C to +85°C BC2046E TSC2046EIZQCR Tape and Reel, 2500
(1)
For the most current package and ordering information, see the Package Option Addendum located at the end of this data sheet, or see the TI web
site at www.ti.com.
