Evaluation Board User Guide UG-084
Rev. B | Page 5 of 8
NONINVERTING CONFIGURATION
When using this board in a noninverting configuration, with a
gain larger than 1, there are two recommended ways to place the
gain resistor. The first way is to place the gain resister in the R1
location and uses a 0 Ω for the R2 location to short to ground.
The second way is to place the gain resister between the first pad
of R1 and ground, without using a second resistor (see Figure 8).
08787-008
Figure 8. Noninverting Configuration with a Gain of Higher Then 1
