MSP430F5438A
,
MSP430F5437A
,
MSP430F5436A
,
MSP430F5435A
MSP430F5419A, MSP430F5418A
SLAS655E –JANUARY 2010–REVISED JULY 2015
www.ti.com
1.3 Description
The TI MSP430™ family of ultra-low-power microcontrollers consists of several devices featuring different
sets of peripherals targeted for various applications. The architecture, combined with extensive low-power
modes, is optimized to achieve extended battery life in portable measurement applications. The device
features a powerful 16-bit RISC CPU, 16-bit registers, and constant generators that contribute to
maximum code efficiency. The digitally controlled oscillator (DCO) allows the device to wake up from low-
power modes to active mode in 3.5 µs (typical).
The MSP430F543xA and MSP430F541xA series are microcontroller configurations with three 16-bit
timers, a high-performance 12-bit ADC, up to four universal serial communication interfaces (USCIs), a
hardware multiplier, DMA, an RTC module with alarm capabilities, and up to 87 I/O pins.
Typical applications for this device include analog and digital sensor systems, digital motor control, remote
controls, thermostats, digital timers, and hand-held meters.
Device Information
(1)
PART NUMBER PACKAGE BODY SIZE
(2)
MSP430F5438AZQW MicroStar Junior™ BGA (113) 7 mm × 7 mm
MSP430F5438APZ LQFP (100) 14 mm × 14 mm
MSP430F5437APN LQFP (80) 12 mm × 12 mm
(1) For the most current part, package, and ordering information, see the Package Option Addendum in
Section 8, or see the TI website at www.ti.com.
(2) The sizes shown here are approximations. For the package dimensions with tolerances, see the
Mechanical Data in Section 8.
2 Device Overview Copyright © 2010–2015, Texas Instruments Incorporated
Submit Documentation Feedback
Product Folder Links: MSP430F5438A MSP430F5437A MSP430F5436A MSP430F5435A MSP430F5419A
MSP430F5418A
