PIC18F2620-I/SP 产品设计参考手册 - Microchip（微芯）
制造商:
Microchip（微芯）
分类:
微控制器
封装:
DIP-28
描述:
PIC18F2525/2620/4525/4620 8 位微控制器Microchip 的 PIC18F 微控制器是 Microchip 产品线中功能最强大的 8 位设备。 该系列包含的 CAN、LIN 和以太网功能是完整系列外围设备的一部分，可满足嵌入式应用和版本的需求，采用 XLP（极低功耗）技术，用于功耗为关键考量的应用。 PIC18F2525/2620/4525/4620 系列微控制器基于 Microchip 的 PIC18 体系结构，提供 31 级 硬件堆栈和 75 指令。 这些 MCU 提供高达 10 个 MIPS、多达 64 kb 的程序存储器、多达 3968 kb 的 RAM 和 124 kb 的数据 EEPROM。 板载可配置 RC 振荡器。### 微控制器功能40 MHz 最大 CPU 速度 75 指令 - 通过扩展指令集支持 83 指令 31 级硬件堆栈 内部振荡器 - 可选频率范围 8 mHz 至 31 kHz 25 个输入/输出引脚 - PIC18F2525/2620 型号 36 个输入/输出引脚 - PIC18F4525/4620 型号 nanoWatt 技术 通电重置 (POR) 通电计时器 (PWRT) 振荡器启动计时器 (OST) 掉电重置 (BOR) 延长监控计时器 (WDT) 高电压/低电压检测 (HLVD) 模块 在线串行编程 (ICSP) 在线调试 (ICD) ### 外设10 位模拟到数字转换器 (ADC) - PIC18F2525/2620 10 通道；PIC18F4525/4620 13 通道 采集、比较、PWM 模块 - PIC18F2525/2620 x 2、PIC18F4525/4620 x 1 一个增强型采集、比较、PWM 模块 - 仅 PIC18F4525/4620 型号 两个比较器 一个 8 位计时器 三个 16 位计时器 主同步串行端口 (MSSP) 模块，带有 SPI 和 I2C 增强型通用同步异步接收器发射器 (EUSART) ### PIC18 微控制器展开
