Features UM1879
6/39 DocID027676 Rev 2
1 Features
STM32L476VGT6 microcontroller featuring 1 Mbyte of Flash memory and 128 Kbytes
of RAM in LQFP100 package
On-board ST-LINK/V2-1 supporting USB re-enumeration capability
Three different interfaces supported on USB:
– Virtual com port
– Mass storage
– Debug port
Mbed-enabled (mbed.org)
LCD 24 segments, 4 commons in DIP 28 package
Seven LEDs:
– LD1 (red/green) for ST-LINK/V2-1 USB communication
– LD2 (red) for 3.3 V power on
– LD3 over current (red)
– LD4 (red), LD5 (green) two user LEDs
– LD6 (green), LD7 (red) USB OTG FS LEDs
Pushbutton (reset)
Four direction joystick with selection
USB OTG FS with micro-AB connector
SAI Audio DAC, stereo with output jack
Digital microphone MEMS
Accelerometer and magnetometer MEMS
Gyroscope MEMS
128-Mbit Quad-SPI Flash memory
MCU current ammeter with 4 ranges and auto calibration
I2C extension connector for external board
Four power supply options:
–ST-LINK/V2-1
– USB FS connector
– External 5V
– CR2032 battery (not provided)
Extension connectors
Comprehensive free software including a variety of examples, part of STM32Cube
package
