TMS320C5517
SPRS727C –AUGUST 2012–REVISED APRIL 2014
TMS320C5517 Fixed-Point Digital Signal Processor
1 Device Overview
1.1 Features
1
– Direct Memory Access (DMA) Controller
• CORE:
• Four DMA with Four Channels Each
– High-Performance, Low-Power, TMS320C55x
Fixed-Point Digital Signal Processor
– Three 32-Bit General-Purpose (GP) Timers
• 13.33- to 5-ns Instruction Cycle Time
• One Selectable as a Watchdog or GP
• 75- to 200-MHz Clock Rate
• Clocking Options, Including External
General-Purpose I/O (GPIO) Clock Input
• One or Two Instructions Executed per Cycle
– Two MultiMedia Card and Secure Digital
• Dual Multiply-and-Accumulate Units (Up to
(eMMC, MMC, and SD) Interfaces
450 Million Multiply-Accumulates per Second
– Serial Port Interface (SPI) with Four Chip
[MMACS])
Selects
• Two Arithmetic and Logic Units (ALUs)
– Master and Slave Inter-Integrated Circuit (I
2
C
• Three Internal Data or Operand Read Buses
Bus)
and Two Write Buses
– Three Inter-IC Sound (I
2
S Bus) Modules for
• Software-Compatible with C55x Devices
Data Transport
• Industrial Temperature Devices Available
– 10-Bit 4-Input Successive Approximation (SAR)
– 320KB of Zero-Wait State On-Chip RAM:
ADC
• 64KB of Dual-Access RAM (DARAM),
– IEEE-1149.1 (JTAG)
8 Blocks of 4K x 16-Bit
Boundary-Scan-Compatible
• 256KB of Single-Access RAM (SARAM),
– Up to 26 GPIO Pins (Multiplexed with Other
32 Blocks of 4K x 16-Bit
Functions)
– 128KB of Zero Wait-State On-Chip ROM
• POWER:
(4 Blocks of 16K x 16-Bit)
– Four Core Isolated Power Supply Domains:
– Tightly Coupled FFT Hardware Accelerator
Analog, RTC, CPU and Peripherals, and USB
• PERIPHERAL:
– Four I/O Isolated Power Supply Domains: RTC
– One Universal Host-Port Interface (UHPI) with
I/O, EMIF I/O, USB PHY, and DV
DDIO
16-Bit Muxed Address or Data Bus
– 1.05-V Core, 1.8-, 2.75-, or 3.3-V I/Os
– Master and Slave Multichannel Serial Ports
– 1.3-V Core, 1.8-, 2.75-, or 3.3-V I/Os
Interface (McSPI) with Three Chip Selects
– 1.4-V Core, 1.8-, 2.75-, or 3.3-V I/Os
– Master and Slave Multichannel Buffered Serial
• CLOCK:
Ports Interface (McBSP)
– Real-Time Clock (RTC) with Crystal Input,
– 16- and 8-Bit External Memory Interface (EMIF)
Separate Clock Domain, and Power Supply
with Glueless Interface to:
– Software-Programmable Phase-Locked Loop
• 8- or 16-Bit NAND Flash, 1- or 4-Bit ECC
(PLL) Clock Generator
• 8- and 16-Bit NOR Flash
• BOOTLOADER:
• Asynchronous Static RAM (SRAM)
– On-Chip ROM Bootloader
• SDRAM or mSDRAM (1.8, 2.75, and 3.3 V)
• Each Peripheral Supports Unencrypted
– 3.84375M x 16-Bit Maximum Addressable
Booting
External Memory Space (SDRAM or mSDRAM)
• PACKAGE:
– Universal Asynchronous Receiver/Transmitter
– 196-Terminal Pb-Free Plastic BGA (Ball Grid
(UART)
Array) (ZCH Suffix), 0.65-mm Pitch
– Device USB Port with Integrated 2.0 High-
Speed PHY that Supports:
• USB 2.0 Full- and High-Speed Devices
1
An IMPORTANT NOTICE at the end of this data sheet addresses availability, warranty, changes, use in safety-critical applications,
intellectual property matters and other important disclaimers. PRODUCTION DATA.
