1.3 Description
The F2803x Piccolo™ family of microcontrollers provides the power of the C28x core and Control Law
Accelerator (CLA) coupled with highly integrated control peripherals in low pin-count devices. This family
is code-compatible with previous C28x-based code, and also provides a high level of analog integration.
An internal voltage regulator allows for single-rail operation. Enhancements have been made to the
HRPWM to allow for dual-edge control (frequency modulation). Analog comparators with internal 10-bit
references have been added and can be routed directly to control the PWM outputs. The ADC converts
from 0 to 3.3-V fixed full-scale range and supports ratio-metric V
REFHI
/V
REFLO
references. The ADC
interface has been optimized for low overhead and latency.
(1) For more information on these devices, see Section 9, Mechanical Packaging and Orderable
Information.
Device Information
(1)
PART NUMBER PACKAGE BODY SIZE
TMS320F28035PN LQFP (80) 12.0 mm × 12.0 mm
TMS320F28034PN LQFP (80) 12.0 mm × 12.0 mm
TMS320F28033PN LQFP (80) 12.0 mm × 12.0 mm
TMS320F28032PN LQFP (80) 12.0 mm × 12.0 mm
TMS320F28031PN LQFP (80) 12.0 mm × 12.0 mm
TMS320F28030PN LQFP (80) 12.0 mm × 12.0 mm
TMS320F28035PAG TQFP (64) 10.0 mm × 10.0 mm
TMS320F28034PAG TQFP (64) 10.0 mm × 10.0 mm
TMS320F28033PAG TQFP (64) 10.0 mm × 10.0 mm
TMS320F28032PAG TQFP (64) 10.0 mm × 10.0 mm
TMS320F28031PAG TQFP (64) 10.0 mm × 10.0 mm
TMS320F28030PAG TQFP (64) 10.0 mm × 10.0 mm
TMS320F28035RSH VQFN (56) 7.0 mm × 7.0 mm
TMS320F28034RSH VQFN (56) 7.0 mm × 7.0 mm
TMS320F28033RSH VQFN (56) 7.0 mm × 7.0 mm
TMS320F28032RSH VQFN (56) 7.0 mm × 7.0 mm
TMS320F28031RSH VQFN (56) 7.0 mm × 7.0 mm
TMS320F28030RSH VQFN (56) 7.0 mm × 7.0 mm
