Copyright © 2009–2016, Texas Instruments IncorporatedDevice Comparison
Submit Documentation Feedback
Product Folder Links: TMS320F28030 TMS320F28031 TMS320F28032 TMS320F28033 TMS320F28034
TMS320F28035
6
TMS320F28030
,
TMS320F28031
,
TMS320F28032
TMS320F28033
,
TMS320F28034
,
TMS320F28035
SPRS584K –APRIL 2009–REVISED JUNE 2016
www.ti.com
(1) A type change represents a major functional feature difference in a peripheral module. Within a peripheral type, there may be minor differences between devices that do not affect the
basic functionality of the module. These device-specific differences are listed in the C2000 Real-Time Control Peripherals Reference Guide and in the peripheral reference guides.
3 Device Comparison
Table 3-1 lists the features of the TMS320F2803x devices.
Table 3-1. Device Comparison
FEATURE TYPE
(1)
28030
(60 MHz)
28031
(60 MHz)
28032
(60 MHz)
28033
(60 MHz)
28034
(60 MHz)
28035
(60 MHz)
Package Type
80-Pin
PN
LQFP
64-Pin
PAG
TQFP
56-Pin
RSH
VQFN
80-Pin
PN
LQFP
64-Pin
PAG
TQFP
56-Pin
RSH
VQFN
80-Pin
PN
LQFP
64-Pin
PAG
TQFP
56-Pin
RSH
VQFN
80-Pin
PN
LQFP
64-Pin
PAG
TQFP
56-Pin
RSH
VQFN
80-Pin
PN
LQFP
64-Pin
PAG
TQFP
56-Pin
RSH
VQFN
80-Pin
PN
LQFP
64-Pin
PAG
TQFP
56-Pin
RSH
VQFN
Instruction cycle – 16.67 ns 16.67 ns 16.67 ns 16.67 ns 16.67 ns 16.67 ns
Control Law Accelerator (CLA) 0 No No No Yes No Yes
On-chip flash (16-bit word) – 16K 32K 32K 32K 64K 64K
On-chip SARAM (16-bit word) – 6K 8K 10K 10K 10K 10K
Code security for on-chip
flash/SARAM/OTP blocks
– Yes Yes Yes Yes Yes Yes
Boot ROM (8K x 16) – Yes Yes Yes Yes Yes Yes
One-time programmable (OTP) ROM
(16-bit word)
– 1K 1K 1K 1K 1K 1K
ePWM channels 1 14 12 8 14 12 8 14 12 8 14 12 8 14 12 8 14 12 8
eCAP inputs 0 1 1 1 1 1 1
eQEP modules 0 1 1 1 1 1 1
Watchdog timer – Yes Yes Yes Yes Yes Yes
12-Bit ADC
MSPS
3
2.0 2.0 4.6 4.6 4.6 4.6
Conversion Time 500.00 ns 500.00 ns 216.67 ns 216.67 ns 216.67 ns 216.67 ns
Channels 16 14 13 16 14 13 16 14 13 16 14 13 16 14 13 16 14 13
Temperature Sensor Yes Yes Yes Yes Yes Yes
Dual Sample-and-Hold Yes Yes Yes Yes Yes Yes
32-Bit CPU timers – 3 3 3 3 3 3
High-resolution ePWM Channels 1 – – 7 6 4 7 6 4 7 6 4 7 6 4
High-resolution Capture (HRCAP)
Modules
0 – – 2 2 – 2 2 – 2 2 – 2 2 –
Comparators with Integrated DACs 0 3 3 3 3 3 3
Inter-integrated circuit (I2C) 0 1 1 1 1 1 1
Enhanced Controller Area Network
(eCAN)
0 1 1 1 1 1 1
Local Interconnect Network (LIN) 0 1 1 1 1 1 1
Serial Peripheral Interface (SPI) 1 2 1 1 2 1 1 2 1 1 2 1 1 2 1 1 2 1 1
Serial Communications Interface (SCI) 0 1 1 1 1 1 1
I/O pins
(shared)
GPIO – 45 33 26 45 33 26 45 33 26 45 33 26 45 33 26 45 33 26
AIO – 6 6 6 6 6 6
