WL1807MOD, WL1837MOD
SWRS170H –AUGUST 2014–REVISED OCTOBER 2015
WL18x7MOD WiLink™ 8 Dual-Band Industrial Module –
Wi-Fi
®
, Bluetooth
®
, and Bluetooth Low Energy (LE)
1 Device Overview
1.1 Features
1
space
• General
• Bluetooth and Bluetooth LE (WL1837MOD
– Integrates RF, Power Amplifiers (PAs), Clock,
Only)
RF Switches, Filters, Passives, and Power
Management – Bluetooth 4.1 Compliance and CSA2 Support
– Quick Hardware Design With TI Module – Host Controller Interface (HCI) Transport for
Collateral and Reference Designs Bluetooth Over UART
– Operating Temperature: –40°C to 85°C – Dedicated Audio Processor Support of SBC
Industrial Temperature Grade Encoding + A2DP
– Small Form Factor: 13.3 × 13.4 × 2 mm – Dual-Mode Bluetooth and Bluetooth LE
– 100-Pin MOC Package – TI's Bluetooth- and Bluetooth LE-Certified Stack
– FCC, IC, ETSI/CE, and TELEC Certified With • Key Benefits
Chip Antennas
– Reduces Design Overhead
• Wi-Fi
– Differentiated Use-Cases by Configuring WiLink
– WLAN Baseband Processor and RF Transceiver 8 Simultaneously in Two Roles (STA and AP) to
Support of IEEE Std 802.11a, 802.11b, 802.11g, Connect Directly With Other Wi-Fi Devices on
and 802.11n Different RF Channel (Wi-Fi Networks)
– 20- and 40-MHz SISO and 20-MHz 2 × 2 MIMO – Best-in-Class Wi-Fi With High-Performance
at 2.4 GHz for High Throughput: 80 Mbps Audio and Video Streaming Reference
(TCP), 100 Mbps (UDP) Applications With Up to 1.4X the Range Versus
One Antenna
– 2.4-GHz MRC Support for Extended Range and
5-GHz Diversity Capable – Different Provisioning Methods for In-Home
Devices Connectivity to Wi-Fi in One Step
– Fully Calibrated: Production Calibration Not
Required – Lowest Wi-Fi Power Consumption in Connected
Idle (< 800 µA)
– 4-Bit SDIO Host Interface Support
– Configurable Wake on WLAN Filters to Only
– Wi-Fi Direct Concurrent Operation
Wake up the System
(Multichannel, Multirole)
– Wi-Fi-Bluetooth Single Antenna Coexistence
1.2 Applications
• Internet of Things (IoT) • Industrial and Home Automation
• Multimedia • Smart Gateway and Metering
• Home Electronics • Video Conferencing
• Home Appliances and White Goods • Video Camera and Security
1
An IMPORTANT NOTICE at the end of this data sheet addresses availability, warranty, changes, use in safety-critical applications,
intellectual property matters and other important disclaimers. PRODUCTION DATA.
