Visit analog.com
3
Main Product Introduction
Function Block Part Number Description Key Feature Benefit
TC/RTD
Input Devices
ADC
AD779x
16-/24-bit, 4 SPS to 500 SPS,
Σ-Δ ADC
Low power (300 μA to 450 μA), internal PGA, ref, clock,
buffer, simultaneous 50 Hz/60 Hz rejection
Very low power dissipation 450 μA max
AD7124
24-bit, multichannel, low
power, low noise, Σ-Δ ADC
Three power modes; low power: 24 nV rms at 1.17
SPS, gain = 128 (255 μA typical); output data rate: full
power: 9.38 SPS to 19,200 SPS; programmable gain
(1 to 128); band gap reference with 15 ppm/°C drift
maximum (65 μA)
High integration, diagnostic functions
Integrated Solution
ADuCM360/
ADuCM361
ARM
®
Cortex
®
-M3
Microcontroller
Integrate dual/single 24-bit Σ-Δ ADC; UART, I
2
C and
2 × SPI serial I/O; 16-bit PWM controller; 19-lead
multifunction GPIO ports;128 kB Flash/EE memory,
8 kB SRAM
ADuCM360/ADuCM361 is designed
for direct interfacing to external
precision sensors in both wired and
battery-powered applications
4 mA to 20 mA/
0 V to 10 V
Input Devices
ADC
AD719x
Multichannel, 4.8 kHz,
ultralow noise, 24-bit Σ-Δ ADC
RMS noise: 11 nV at 4.7 Hz (gain = 128), up to 22
noise-free bits (gain = 1), programmable gain (1 to
128) output data rate: 4.7 Hz to 4.8 kHz; AD714 with
integrated PGA
2 differential/4 pseudo differential,
8 differential/16 pseudo differential
input channels
AD7606/
AD7606-4/
AD7606-6
4-channel/6-channel/
8-channel, ±10 V
simultaneous sampling
Bipolar input ranges with single 5 V power supply,
serial and parallel interface; >90 dB SNR
±10 V full input range, 1 mΩ impedance,
synchronous sampling
AD7173-8
Fast settling, highly accurate,
low power, 8-channel/
16-channel, multiplexed ADC
Fast and flexible output rate: 1.25 SPS to 31.25 kSPS
channel scan data rate (161 μs settling); performance
specifications 17.5 noise free bits at 31.25 kSPS;
23 noise free bits at 1.25 SPS; INL: ±3 ppm/FSR
30 kSPS data rate; high free noise
resolution; 4 GPIO
ADAS3022
8-channel, 16-bit, 1 MSPS
SAD ADC
High input common-mode rejection: >100 dB; on-chip
4.096 V reference and buffer; differential input voltage
range: ±24.576 V maximum
>500 MΩ input impedance
AD7689
8-channel, 16-bit, SAR ADC,
single power supply
INL: ±0.4 LSB typical, ±1.5 LSB maximum; dynamic
range: 93.8 dB; SINAD: 92.5 dB at 20 kHz; THD: −100 dB
at 20 kHz; single-supply 2.3 V to 5.5 V operation with
1.8 V to 5.5 V logic interface
Throughput 250 kSPS
AD7177-2
32-bit, 10 kSPS, Σ-Δ ADC
with 100
µs settling and true
rail-to-rail buffers
32-bit data output; fast and flexible output rate: 5 SPS
to 10 kSPS; performance specifications: 19.1 noise free
bits at 10 kSPS; 24.6 noise free bits at 5 SPS; 85 dB
filter rejection of 50 Hz and 60 Hz with 50 ms settling
32-bit, low noise, multichannel
Amplifiers
AD8422
Rail-to-rail
instrumentation amplifier
330 μA maximum quiescent current; 8 nV/√Hz
maximum input voltage noise at 1 kHz; excellent ac
specifications: 80 dB minimum CMRR at 10 kHz
(G = 1); high precision dc performance 150 dB
minimum CMRR (G = 1000); wide supply range: 4.6 V
to 36 V single-supply, ±2.3 V to ±18 V dual supply; gain
range: 1 to 1000
High precision, low power, low noise
ADA4096-2/
ADA4096-4
with OVP
Dual/quad micropower
operation and rail-to-rail input
and output ranges
Low power: 60 μA per amplifier typical; unity-gain
bandwidth 800 kHz typ @ V
SY
= ±15 V; 550 kHz typ
@ V
SY
= ±5 V; 465 kHz typ @ V
SY
= ±1.5 V; low offset
voltage: 300 μV maximum
Input overvoltage protection, 32 V above
and below the supply rails; unity-gain stable
Muxes
ADG5412F
Four independent single-pole/
single-throw (SPST) switches
4 kV human body model (HBM) ESD rating; low on
resistance (10 Ω); ±5 V to ±25 V dual-supply operation;
5 V to 44 V; single-supply operation; fully specified at
±15 V, ±20 V, +5 V, +12 V, and +36 V
With OVP and power-off protection
ADG5208F/
ADG5209F
ADG5208F and ADG5209F
are 8:1 and dual 4:1 analog
multiplexers
Overvoltage protection up to −55 V and +55 V; low on
capacitance: ADG5208F: 20 pF; ADG5209F: 14 pF
OVP
ADG508F/
ADG509F
ADG508F comprising
eight single channels/
ADG509F comprising four
differential channels
Low on resistance (270 Ω typical); fast switching times:
T
ON
230 ns maximum; T
OFF
130 ns maximum; low power
dissipation (3.3 mW maximum)
OVP; TTL and CMOS compatible inputs
