Visit analog.com
5
Function Block Part Number Description Key Feature Benefit
Multiple Analog
Output Devices
DACs
AD5686/
AD5684R
Quad, 16-/12-bit nanoDAC
®
with on-chip reference and
SPI inerface
High relative accuracy (INL): ±2 LSB, low drift 2.5 V
reference 2 ppm/°C, total unadjusted error (TUE):
0.1% of FSR maximum, offset error: 1.5 mV maximum,
gain error: 0.1 % of FSR maximum, high drive
capability: 20 mA, 0.5 V from supply rails
Rail-to-rail, voltage output DAC; the
device includes a 2.5 V, 2 ppm/°C internal
reference (enabled by default) and a gain
select pin giving a full-scale output of 2.5 V
(gain = 1) or 5 V (gain = 2)
Integrated Solutions
AD5755/
AD5735/
AD5757/
AD5737
Quad-channel, 16-/12-bit,
current/voltage output DAC
with dynamic power control
Dynamic power control for thermal management,
voltage or current output on the same pin, IOUT
range: 0 mA/4 mA to 20 mA, or 0 mA to 24 mA,
V
OUT
range: 0 V to 5 V, 0 V to 10 V, ±5 V, ±10 V, ±6 V,
±12 V; on-chip reference
Industry’s first data converter with dynamic
power control functionality that provides
energy saving and enhances the reliability
of process control I/O systems operating
HART
AD5700/
AD5700-1
Half-duplex HART modem/
Half-duplex HART modem
with internal oscillator
HART-compliant fully integrated FSK modem, 1200 Hz
and 2200 Hz sinusoidal shift frequencies, 115 µA
maximum supply current in receive mode, integrated
receive band-pass filter, minimal external components
required, 1.71 V to 5.5 V power supply/0.5% precision
internal oscillator
Lowest power consumption;
smallest package; high integtation;
high driver capability
Reference Circuit ID Description
CN0278 Isolated, 4-channel, thermocouple/RTD temperature measurement system with 0.5°C accuracy
CN0310 24-bit, 250 kSPS single-supply data acquisition system
CN0251 24-bit, 4.7 Hz, 4-channel, analog data acquisition system
CN0255 16-bit, 100 kSPS, single-supply, low power data acquisition system
CN0254 16-bit, 250 kSPS, 8-channel, single-supply, isolated data acquisition system
CN0325 PLC/DCS universal analog input using either 4-pin or 6-pin terminal block
CN0270 Complete 4 mA to 20 mA HART solution
CN0321 Fully isolated, single-channel voltage and 4 mA to 20 mA output with HART
CN0233 16-bit, isolated, industrial voltage and current output DAC with isolated dc-to-dc supplies
CN0267 Complete 4 mA to 20 mA looped power field instrument with HART interface
RD_ADuC7061 Low power 4-wire pressure transmitter
