ATmega16M1/32M1/64M1 [DATASHEET]
8209ES–AVR–11/2012
Note: 1. Only for Atmel Atmega32M1/64M1.
2. On the engineering samples, the ACMPN3 alternate function is not located on PC4. It is located on PE2.
2. Overview
The Atmel ATmega16M1/32M1/64M1 is a low-power CMOS 8-bit microcontroller based on the AVR enhanced
RISC architecture. By executing powerful instructions in a single clock cycle, the ATmega16M1/32M1/64M1
achieves throughputs approaching 1 MIPS per MHz allowing the system designer to optimize power consumption
versus processing speed.
12 PD4 I/O
ADC1 (Analog Input Channel 1)
RXD (UART Rx data)
RXLIN (LIN Receive Input)
ICP1A (Timer 1 input capture alternate A input)
SCK_A (Programming & alternate SPI Clock)
PCINT20 (Pin Change Interrupt 20)
13 PD5 I/O
ADC2 (Analog Input Channel 2)
ACMP2 (Analog Comparator 2 Positive Input)
PCINT21 (Pin Change Interrupt 21)
14 PD6 I/O
ADC3 (Analog Input Channel 3)
ACMPN2 (Analog Comparator 2 Negative Input)
INT0 (External Interrupt 0 Input)
PCINT22 (Pin Change Interrupt 22)
15 PD7 I/O
ACMP0 (Analog Comparator 0 Positive Input)
PCINT23 (Pin Change Interrupt 23)
31 PE0 I/O or I
RESET (Reset Input)
OCD (On Chip Debug I/O)
PCINT24 (Pin Change Interrupt 24)
10 PE1 I/O
XTAL1 (XTAL Input)
OC0B (Timer 0 Output Compare B)
PCINT25 (Pin Change Interrupt 25)
11 PE2 I/O
XTAL2 (XTAL Output)
ADC0 (Analog Input Channel 0)
PCINT26 (Pin Change Interrupt 26)
Table 1-1. Pinout description. (Continued)
QFN32 pin
number Mnemonic Type Name, function, and alternate function
