1
PROM PROGRAMMING FLOW FOR UT28F256QLE and UT28F256LVQLE PROMs
Aeroflex Colorado Springs’ new (June 2006) UT28F256QLE and UT28F256LVQE do not require any Post- Program Condition-
ing. NOTE: Many customers have purchased Aeroflex’s Legacy PROMs - DO NOT use the Post Programming kit that was pro-
vided with the Legacy PROMs. The UT28F256QLE and UT28F256LVQLE will be damaged if connected to the burn-in stimulus
card.
Algorithm Download:
Go to www.bpmicro.com.
Under software select Downloads.
Register and then login
Select BPWIN (approx. 56MB file size)
Install BPWIN
Note: Software versions 4.61 or higher are approved releases.
Programming:
To select a device hit the Device tab below and type in Aeroflex and then highlight the device type you want to program.
To load data pattern hit the Data Pattern tab below.
Use default settings for Device Config. (Set 1 wide, 1 bank; Mode: Sets)
Be sure that Continuity, Blank Check and Verify are checked. Set Verify to Twice.
Hit the PROGRAM tab to start programming the device.
Standard Products
UT28F256QLE and UT28F256LVQLE PROMs
Programming User Guide
October, 2006
