2007-2011 Microchip Technology Inc. Advance Information DS41228F-page 3
PIC10F200/202/204/206
FIGURE 2-3: PIC10F202/206 PROGRAM
MEMORY MAP
2.4 Oscillator Calibration Bits
The oscillator Calibration bits are stored at the Reset
vector as the operand of a MOVLW instruction.
Programming interfaces must allow users to program
the Calibration bits themselves for custom trimming of
the INTOSC. Capability for programming the
Calibration bits when programming the entire memory
array must also be maintained for backwards
compatibility.
2.5 Backup OSCCAL Value
The backup OSCCAL value, 0x104/0x204, is a factory
reserved location where the OSCCAL value is stored
during testing of the INTOSC. This location is not
erased during a standard Bulk Erase, but is erased if
the PC is moved into configuration memory prior to
invoking a Bulk Erase. If this value is erased, it is the
user’s responsibility to rewrite it back to this location for
future use.
User Memory
Space
000h
1FFh
Reset Vector
0FFh
100h
On-chip
User
Program
Memory
User ID Locations
Reserved
Configuration Word
200h
203h
204h
3FEh
3FFh
23Fh
240h
Unimplemented
1FEh
Backup OSCCAL value
205h
Config Memory
Space
