PIC16C55X
DS30261D-page 4 2002 Microchip Technology Inc.
In the configuration memory space, 0x2000-0x20FF
are utilized. When in a configuration memory, as in the
user memory, the 0x2000-0x20FF segment is repeat-
edly accessed as the PC exceeds 0x20FF (see
Figure 2-1).
A user may store identification information (User ID) in
four ID locations. The User ID locations are mapped in
[0x2000: 0x2003]. These locations read out normally
even after code protection is enabled.
FIGURE 2-1: PROGRAM MEMORY MAPPING
Note 1: All other locations in PICmicro
MCU
configuration memory are reserved and
should not be programmed.
2: Only the low order 4 bits of the User ID
locations may be included in the device
checksum. See Section 4.3 for checksum
calculation details.
0.5KW 1KW 2KW
Implemented Implemented
Implemented
Reserved
Reserved Reserved Reserved
Reserved Reserved Reserved
0
3FF
400
7FF
800
BFF
C00
FFF
1000
1FFF
2000
2008
2100
3FFF
ID Location
ID Location
ID Location
ID Location
Reserved
Reserved
Reserved
Configuration Word
2000
2001
2002
2003
2004
2005
2006
2007
1FF
Reserved
Reserved
Implemented
Reserved
Reserved
