AN3109 FIFO emulation with DMA
Doc ID 16795 Rev 1 5/10
1.2 RAM FIFO emulation in STM32 microcontrollers
The DMA capability of STM32 microcontrollers greatly simplifies the FIFO implementation.
DMA is an efficient way of implementing RAM FIFO based on the principle described in
Section 1.1: FIFO overview.
DMA features that simplify the FIFO implementation:
● Independent source and destination transfer sizes (byte, half-word, word), to emulate
packing and unpacking
● Support for circular buffer management
● Access to Flash memory, SRAM, APB1, APB2 and AHB peripherals as source and
destination
● Programmable number of data items to be transferred: up to 65536
All these features concur to minimize the software overhead associated with data storage.
The DMA memory increment mode is very useful because, with it, the data pointer can be
automatically incremented.
Here, the DMA buffer emulates the FIFO buffer. The write buffer pointer (DMA pointer) is
automatically incremented and the DMA count is automatically decremented when the FIFO
is filled.
The read buffer locations are incremented by software every time data are retrieved from the
FIFO buffer.
1.3 FIFO software implementation
1.3.1 Implementation
This example describes the basic architecture of a circular buffer FIFO for a communication
peripheral. The USART is provided as an example.
Data are received and stored into the DMA circular buffer, where they remain until they are
removed and manipulated.
The transmitter transmits n data items using DMA. The message length (n) is known in
advance.
The receiver receives m (potentially unknown) data items using DMA. It is still possible to
get the peripheral’s RXNE interrupt even when using DMA. In fact, the interrupt from the
peripheral emulates the FIFO nonempty interrupt.
For reception:
● There is no need to clear the RXNE flag in the receive interrupt routine, as it was
automatically cleared by the DMA data read operation. However, the interrupt remains
pending in the NVIC (even though the RXNE flag is no longer set).
● Two buffers are used:
– RxBuffer2: it is defined as the DMA memory base address from which data will be
read. This buffer emulates the FIFO buffer.
– RxBuffer2_SW: it is a software buffer used, inside the receive interrupt routine, to
transfer the received data from the FIFO. It is the final data storage destination.
