PIC16(L)F1704/8
DS40001715B-page 12 Preliminary 2013 Microchip Technology Inc.
RC1/AN5/C1IN1-/C2IN1-/
OPA1IN-/SDI
(1)
/SDA
(3)
/
CLCIN2
(1)
RC1 TTL/ST CMOS General purpose I/O.
AN5 AN — ADC Channel 5 input.
C1IN1-
AN — Comparator C1 negative input.
C2IN1-
AN — Comparator C2 negative input.
OPA1IN- AN — Operational Amplifier 1 inverting input.
SDI CMOS — SPI data input.
SDA I
2
CODI
2
C™ data input/output.
CLCIN2 ST — Configurable Logic Cell source input.
RC2/AN6/C1IN2-/C2IN2-/
OPA1OUT
RC2 TTL/ST CMOS General purpose I/O.
AN6 AN — ADC Channel 6 input.
C1IN2- AN — Comparator C1 negative input.
C2IN2- AN — Comparator C2 negative input.
OPA1OUT
—AN
Operational Amplifier 1 output.
RC3/AN7/C1IN3-/C2IN3-/
OPA2OUT/CCP2
(1)
/SS
(1)
/
CLCIN0
(1)
RC3 TTL/ST CMOS General purpose I/O.
AN7 AN — ADC Channel 7 input.
C1IN3- AN — Comparator C1 negative input.
C2IN3- AN — Comparator C2 negative input.
OPA2OUT
—AN
Operational Amplifier 2 output.
CCP2 ST CMOS Capture/Compare/PWM2.
SS
ST — Slave Select input.
CLCIN0 ST — Configurable Logic Cell source input.
RC4/OPA2IN-/CK
(1)
/CLCIN1
(1)
RC4 TTL/ST CMOS General purpose I/O.
OPA2IN- AN — Operational Amplifier 2 inverting input.
CK ST CMOS USART synchronous clock.
CLCIN1 ST — Configurable Logic Cell source input.
RC5/OPA2IN+/CCP1
(1)
/RX
(1)
RC5 TTL/ST CMOS General purpose I/O.
OPA2IN+ AN — Operational Amplifier 2 non-inverting input.
CCP1 ST CMOS Capture/Compare/PWM1.
RX ST — USART asynchronous input.
V
DD VDD Power — Positive supply.
V
SS VSS Power — Ground reference.
TABLE 1-2: PIC16(L)F1704 PINOUT DESCRIPTION (CONTINUED)
Name Function
Input
Type
Output
Type
Description
Legend: AN = Analog input or output CMOS= CMOS compatible input or output OD = Open Drain
TTL = TTL compatible input ST = Schmitt Trigger input with CMOS levels I
2
C™ = Schmitt Trigger input with I
2
C
HV = High Voltage XTAL = Crystal levels
Note 1: Default peripheral input. Input can be moved to any other pin with the PPS input selection registers. See Register 12-1.
2: All pin outputs default to PORT latch data. Any pin can be selected as a digital peripheral output with the PPS output
selection registers. See Register 12-3.
3: These I
2
C functions are bidirectional. The output pin selections must be the same as the input pin selections.
