2013 Microchip Technology Inc. Preliminary DS40001715B-page 9
PIC16(L)F1704/8
1.0 DEVICE OVERVIEW
The PIC16(L)F1704/8 are described within this data
sheet. They are available in 14-pin and 20-pin DIP
packages and 16-pin and 20-pin QFN packages.
Figure 1-1 shows a block diagram of the
PIC16(L)F1704/8 devices. Table 1-2 shows the pinout
descriptions.
Reference Table 1-1 for peripherals available per device.
TABLE 1-1: DEVICE PERIPHERAL
SUMMARY
Peripheral
PIC16(L)F1704
PIC16(L)F1708
Analog-to-Digital Converter (ADC) ●●
Digital-to-Analog Converter (DAC) ●●
Complementary Output Generator (COG) ●●
Fixed Voltage Reference (FVR) ●●
Zero Cross Detection (ZCD) ●●
Temperature Indicator ●●
Capture/Compare/PWM (CCP/ECCP) Modules
CCP1 ●●
CCP2 ●●
Comparators
C1 ●●
C2 ●●
Configurable Logic Cell (CLC)
CLC1 ●●
CLC2 ●●
CLC3 ●●
Enhanced Universal Synchronous/Asynchronous
Receiver/Transmitter (EUSART)
EUSART ●●
Master Synchronous Serial Ports
MSSP ●●
Op Amp
Op Amp 1 ●●
Op Amp 2 ●●
Pulse Width Modulator (PWM)
PWM3 ●●
PWM4 ●●
Timers
Timer0 ●●
Timer1 ●●
Timer2 ●●
