2009-2021 Microchip Technology Inc. DS20001711M-page 3
24AA01/24LC01B/24FC01
1.0 ELECTRICAL CHARACTERISTICS
Absolute Maximum Ratings
(†)
VCC.............................................................................................................................................................................6.5V
All inputs and outputs w.r.t. V
SS ..........................................................................................................-0.3V to VCC +1.0V
Storage temperature ...............................................................................................................................-65°C to +150°C
Ambient temperature with power applied................................................................................................-40°C to +125°C
ESD protection on all pins 4kV
TABLE 1-1: DC CHARACTERISTICS
† NOTICE: Stresses above those listed under “Absolute Maximum Ratings” may cause permanent damage to the
device. This is a stress rating only and functional operation of the device at those or any other conditions above those
indicated in the operational listings of this specification is not implied. Exposure to maximum rating conditions for
extended periods may affect device reliability.
DC CHARACTERISTICS
Industrial (I): T
A = -40°C to +85°C, VCC = +1.7V to +5.5V
Extended (E): T
A = -40°C to +125°C, VCC = +2.5V to +5.5V (24LC01B)
Extended (E): T
A = -40°C to +125°C, VCC = +1.7V to +5.5V (24FC01)
Param.
No.
Symbol Characteristic Min. Typ. Max. Units Conditions
D1 VIH High-Level Input Voltage 0.7 VCC —— V
D2 V
IL Low-Level Input Voltage — — 0.3 VCC V
D3 VHYS Hysteresis of Schmitt
Trigger Inputs
0.05 VCC —— V(Note)
D4 V
OL Low-Level Output
Voltage
——0.40VIOL = 3.0 mA, VCC =2.5V
D5 I
LI Input Leakage Current — — ±1 µA VIN =VSS or VCC
D6 ILO Output Leakage Current — — ±1 µA VOUT =VSS or VCC
D7 CIN,
C
OUT
Pin Capacitance
(all inputs/outputs)
— — 10 pF VCC = 5.0V (Note)
T
A = 25°C, FCLK =1MHz
D8 I
CCWRITE Operating Current — — 3 mA VCC = 5.5V, SCL = 400 kHz
D9 ICCREAD —— 1mAVCC = 5.5V, SCL = 400 kHz
D10 ICCS Standby Current — — 1 µA SDA = SCL = VCC
WP = V
SS
, I-Temp.
—— 3 µASDA = SCL = VCC
WP = V
SS
, E-Temp. (24FC01)
—— 5 µASDA = SCL = V
CC
WP = V
SS
, E-Temp. (24LC01B)
Note: This parameter is periodically sampled and not 100% tested.
