2003-2019 Microchip Technology Inc. DS20001831F-page 3
25AA128/25LC128
TABLE 1-2: AC CHARACTERISTICS
AC CHARACTERISTICS
Industrial (I): T
A = -40°C to +85°C VCC = 1.8V to 5.5V
Extended (E): T
A = -40°C to +125°C VCC = 2.5V to 5.5V
Param.
No.
Symbol Characteristic Min. Max. Units Conditions
1F
CLK Clock Frequency — 10 MHz 4.5V Vcc 5.5V
—5MHz2.5V Vcc 4.5V
—3MHz1.8V Vcc 2.5V
2T
CSS CS Setup Time 50 — ns 4.5V Vcc 5.5V
100 — ns 2.5V Vcc 4.5V
150 — ns 1.8V Vcc 2.5V
3T
CSH CS Hold Time 100 — ns 4.5V Vcc 5.5V
200 — ns 2.5V Vcc 4.5V
250 — ns 1.8V Vcc 2.5V
4T
CSD CS Disable Time 50 — ns
5T
SU Data Setup Time 10 — ns 4.5V Vcc 5.5V
20 — ns 2.5V Vcc 4.5V
30 — ns 1.8V Vcc 2.5V
6T
HD Data Hold Time 20 — ns 4.5V Vcc 5.5V
40 — ns 2.5V Vcc 4.5V
50 — ns 1.8V Vcc 2.5V
7T
R CLK Rise Time — 100 ns Note 1
8T
F CLK Fall Time — 100 ns Note 1
9T
HI Clock High Time 50 — ns 4.5V Vcc 5.5V
100 — ns 2.5V Vcc 4.5V
150 — ns 1.8V Vcc 2.5V
10 T
LO Clock Low Time 50 — ns 4.5V Vcc 5.5V
100 — ns 2.5V Vcc 4.5V
150 — ns 1.8V Vcc 2.5V
11 T
CLD Clock Delay Time 50 — ns
12 T
CLE Clock Enable Time 50 — ns
13 T
V Output Valid from Clock
Low
—50ns4.5V Vcc 5.5V
— 100 ns 2.5V Vcc 4.5V
— 160 ns 1.8V Vcc 2.5V
14 T
HO Output Hold Time 0 — ns Note 1
15 T
DIS Output Disable Time — 40 ns 4.5V Vcc 5.5V (Note 1)
—80ns2.5V Vcc 4.5V (Note 1)
— 160 ns 1.8V Vcc 2.5V (Note 1)
Note 1: This parameter is periodically sampled and not 100% tested.
2: T
WC begins on the rising edge of CS after a valid write sequence and ends when the internal write cycle is
complete.
3: This parameter is not tested but ensured by characterization. For endurance estimates in a specific
application, please consult the Total Endurance™ Model which can be obtained from Microchip’s website:
www.microchip.com.
