Software User Guide
UG-461
One Technology Way • P. O. Box 9106 • Norwood, MA 02062-9106, U.S.A. • Tel: 781.329.4700 • Fax: 781.461.3113 • www.analog.com
ezLINX iCoupler Isolated Interface Development Environment
PLEASE SEE THE LAST PAGE FOR AN IMPORTANT
WARNING AND LEGAL TERMS AND CONDITIONS.
Rev. 0 | Page 1 of 32
FEATURES
Sample PC application
Open source software
Uses Microsoft .NET Framework, Version 4
Integrates with the ezLINX hardware platform via an
isolated USB
Allows a complete plug and play evaluation and development
experience with 8 isolated communication standards
Isolated USB
Isolated CAN
Isolated RS-485/RS-422
Isolated RS-232
Isolated I
2
C
Isolated SPI
Isolated LVDS
APPLICATIONS
Isolated communication interfaces
SOFTWARE PACKAGE CONTENTS
ezLINX sample PC application install
ezLINX USB drivers
SOFTWARE REQUIREMENTS
Windows XP, Windows Vista, or Windows 7
GENERAL DESCRIPTION
The ezLINX™ hardware platform contains an Analog Devices, Inc.,
ADSP-BF548 processor running the uCLinux™ kernel and the
ezLINX embedded software. A sample PC application is also
provided, interfacing with the ezLINX hardware via an isolated
USB. The embedded software is written in C, and the sample
PC application is written in Microsoft Visual C#; both use
Microsoft .NET Framework, Version 4.0.
The ezLINX software and hardware allow:
• Simultaneously transmitting and receiving data on multiple
isolated interfaces
• Switching between running interfaces
• Viewing data traffic in real time
• Customizing interfaces to suit various applications
• Easy updating of embedded software, or firmware, via an
isolated USB
• Quick saving and loading of an entire configuration for all
communication standards
• Hardware routing of signals between interfaces
The open source nature of both the sample PC application and
the embedded software allows the user to view and edit the
source code of the application to optimize the ezLINX hardware
system for a given application. The source code and sample PC
application can be downloaded from the ezLINX iCoupler
Isolated Interface Development Environment wiki page.
ezLINX SAMPLE PC APPLICATION MAIN WINDOW
10959-001
Figure 1.
