FE-51RD2 - Page 3
SUPPORTED MICROCONTROLLERS
The supported microcontrollers are Atmel W&M 89C51RD2 microcontrollers
and other derivatives that will be announced in the future. The standard
supported package for emulation is PLCC.
FREQUENCY
FE-51RD2 runs from the clock source supplied by the user hardware. The
minimum and maximum frequencies are determined by the emulated chip
characteristics, while the emulator maximum frequency is 40MHz.
HOST CHARACTERSTICS
PC or compatible systems with 8 MByte of RAM, one RS-232C interface card
for the PC, Windows 95 or later.
INPUT POWER
5V, 1.5A power supply supplied.
ITEMS SUPPLIED AS STANDARD
Development system including emulator, programmer and development
board, PLCC emulation header, Windows software with source level
debugger, on-line assembler and disassembler, user's manual, RS-232 cable
and power supply.
OPTIONS
QFP and DIP adapters.
PARTS OF THE SYSTEM
The system includes 3 main hardware boards:
1. FE-51RD2 - In-circuit Emulator
2. DB-51RD2 - Development Board
3. MP-51RD2 Microcontroller Programmer
HARDWARE DESCRIPTION
FE-51RD2 EMULATOR
The first step required to work with the FE-51RD2 board is to be able to
identify its different parts and to understand how the electronics function. This
will help you to take full advantage of all the available capabilities of the FE-
51RD2.
