SPECIFICATION
Supplier : Samsung electro-mechanics Samsung P/N :
CL21C220FBANNWC
Product : Multi-layer Ceramic Capacitor Description :
CAP, 22㎊, 50V, ±1%, C0G, 0805
CL
21 C 220 F B A N N W C
① ②③ ④ ⑤⑥⑦⑧⑨⑩⑪
① Series
Samsung Multi-layer Ceramic Capacitor
② Size
0805 (inch code) L: 2.0 ± 0.1 mm W: ± 0.1 mm
③ Dielectric
C0G
⑧ Inner electrode
④ Capacitance
22
㎊
Termination
⑤ Capacitance
±1
%
Plating
(Pb Free)
tolerance ⑨ Product
Normal
⑥ Rated Voltage
50 V
⑩ Special
Product for Network application
⑦ Thickness
0.65 ± 0.1 mm
⑪ Packaging
Cardboard Type,7"reel
(4,000ea)
A. Samsung Part Number
Sn 100%
Cu
Ni
1.25
B. Samsung Reliability Test and Judgement condition
Capacitance
Within specified tolerance
1㎒±10%
0.5~5Vrms
Q
840 min
Insulation
More than 500Mohm㎌
Rated Voltage 60~120 sec.
Resistance
Appearance
No abnormal exterior appearance Visual inspection
Withstanding
No dielectric breakdown or of the rated voltage
Voltage
mechanical breakdown
Temperature
C0G
Characteristics
(From -55℃ to 125℃, Capacitance change should be within ±30PPM/℃)
Adhesive Strength
No peeling shall be occur on the
500gF, for 10±1 sec.
of Termination
terminal electrode
Bending Strength
Capacitance change : within ±5% Bending to the limit (1mm)
with 1.0mm/sec.
Solderability
More than 75% of terminal surface SnAg3.0Cu0.5 solder
is to be soldered newly
245±5℃, 3±0.3sec.
(preheating : 80~120℃ for 10~30sec.)
Resistance to
Capacitance change : within ±2.5%
Solder pot : 270±5℃, 10±1sec.
Soldering heat
Tan δ, IR : initial spec.
300%
Performance Test condition
