DS1217M Nonvolatile Read/Write Cartridge
2 of 8
ABSOLUTE MAXIMUM RATINGS
Voltage Range on Connection Relative to Ground -0.3V to + 7.0V
Operating Temperature Range
0°C to +70°C
Storage Temperature Range
-40°C to +70°C
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only,
and functional operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is
not implied. Exposure to the absolute maximum rating conditions for extended periods may affect device reliability.
RECOMMENDED DC OPERATING CONDITIONS
(T
A
= 0°C to +70°C)
PARAMETER SYMBOL CONDITIONS MIN TYP MAX UNITS
Power Supply Voltage V
CC
4.5 5.0 5.5 V
Input High Voltage V
IH
2.2 V
CC
V
Input Low Voltage V
IL
0 +0.8 V
DC ELECTRICAL CHARACTERISTICS
(V
CC
= 5V ±10%, T
A
= 0°C to +70°C.)
PARAMETER SYMBOL CONDITIONS MIN TYP MAX UNITS
Input Leakage Current I
IL
-60 +60
A
I/O Leakage Current
CE V
IH
V
CC
I
IO
-10 +10
A
Output Current at 2.4V I
OH
-1.0 -2.0 mA
Output Current at 0.4V I
OL
+2.0 +3.0 mA
Standby Current CE = 2.2V
I
CCS1
15 25 mA
Operating Current I
CCO1
50 100 mA
CAPACITANCE
(T
A
= +25°C)
PARAMETER SYMBOL CONDITIONS MIN TYP MAX UNITS
Input Capacitance C
IN
100 pF
Input/Output Capacitance C
OUT
100 pF
