Absolute Maximum Ratings (Note 1)
If Military/Aerospace specified devices are required,
please contact the National Semiconductor Sales Office/
Distributors for availability and specifications.
Supply Voltage (V
CC
) −0.3V to +6V
Input Voltage (D
IN
) −0.3V to (V
CC
+ 0.3V)
Enable Input Voltage (EN, EN*) −0.3V to (V
CC
+ 0.3V)
Output Voltage (D
OUT+
,D
OUT−
) −0.3V to +5.8V
Short Circuit Duration
(D
OUT+
,D
OUT−
) Continuous
Maximum Package Power Dissipation
@
+25˚C
M Package 1068 mW
Derate M Package 8.5 mW/˚C above +25˚C
Storage Temperature Range −65˚C to +150˚C
Lead Temperature Range
Soldering (4 sec.) +260˚C
Maximum Junction Temperature +150˚C
ESD Rating (Note 7)
(HBM, 1.5 kΩ, 100 pF) ≥ 2kV
(EIAJ, 0 Ω, 200 pF) ≥ 250V
Recommended Operating
Conditions
Min Typ Max Units
Supply Voltage (V
CC
) +4.5 +5.0 +5.5 V
Operating Free Air Temperature (T
A
)
DS90C031BT −40 +25 +85 ˚C
Electrical Characteristics
