3
[Ui] rated insulation
voltage
600 V for signalling circuit certifications UL
600 V for signalling circuit certifications CSA
690 V for signalling circuit conforming to IEC
60947-1
600 V for power circuit certifications UL
600 V for power circuit certifications CSA
690 V for power circuit conforming to IEC 60947-4-1
Electrical durability 0.8 Mcycles 25 A AC-1 at Ue <= 440 V
2 Mcycles 12 A AC-3 at Ue <= 440 V
Power dissipation per
pole
0.36 W AC-3
1.56 W AC-1
Safety cover With
Interlocking type Mechanical
Mounting support Plate
Rail
Standards EN 60947-4-1
EN 60947-5-1
IEC 60947-4-1
IEC 60947-5-1
UL 508
CSA C22.2 No 14
Product certifications BV
CCC
CSA
DNV
GL
GOST
RINA
UL
LROS
Connections - terminals Control circuit : screw clamp terminals 2 cable(s)
1...4 mm² - cable stiffness: solid - without cable end
Control circuit : screw clamp terminals 1 cable(s)
1...4 mm² - cable stiffness: solid - without cable end
Control circuit : screw clamp terminals 2 cable(s)
1...2.5 mm² - cable stiffness: flexible - with cable end
Control circuit : screw clamp terminals 1 cable(s)
1...4 mm² - cable stiffness: flexible - with cable end
Control circuit : screw clamp terminals 2 cable(s)
1...4 mm² - cable stiffness: flexible - without cable
end
Control circuit : screw clamp terminals 1 cable(s)
1...4 mm² - cable stiffness: flexible - without cable
end
Power circuit : screw clamp terminals 2 cable(s)
1...4 mm² - cable stiffness: solid - without cable end
Power circuit : screw clamp terminals 1 cable(s)
1...4 mm² - cable stiffness: solid - without cable end
Power circuit : screw clamp terminals 2 cable(s)
1...2.5 mm² - cable stiffness: flexible - with cable end
Power circuit : screw clamp terminals 1 cable(s)
1...4 mm² - cable stiffness: flexible - with cable end
Power circuit : screw clamp terminals 2 cable(s)
1...4 mm² - cable stiffness: flexible - without cable
end
Power circuit : screw clamp terminals 1 cable(s)
1...4 mm² - cable stiffness: flexible - without cable
end
Tightening torque Control circuit : 1.7 N.m - on screw clamp terminals -
with screwdriver Philips No 2
Control circuit : 1.7 N.m - on screw clamp terminals -
with screwdriver flat Ø 6 mm
Power circuit : 1.7 N.m - on screw clamp terminals -
with screwdriver Philips No 2
Power circuit : 1.7 N.m - on screw clamp terminals -
with screwdriver flat Ø 6 mm
Operating time 4...19 ms opening
12...22 ms closing
Safety reliability level B10d = 20000000 cycles contactor with mechanical
load conforming to EN/ISO 13849-1
B10d = 1369863 cycles contactor with nominal load
conforming to EN/ISO 13849-1
Mechanical durability 15 Mcycles
Operating rate 3600 cyc/h at <= 60 °C
