Absolute Maximum Ratings (Note 1)
If Military/Aerospace specified devices are required,
please contact the National Semiconductor Sales Office/
Distributors for availability and specifications.
Differential Input Voltage
±
Supply Voltage
Supply Voltage (V
+
−V
−
) 16V
Output Short Circuit to V
+
(Note 10)
Output Short Circuit to V
−
(Note 2)
Lead Temperature
(Soldering, 10 sec.) 260˚C
Storage Temperature Range −65˚C to +150˚C
Power Dissipation (Note 3)
Voltage at Output/Input Pin (V
+
) +0.3V, (V
−
) −0.3V
Current at Output Pin
±
18 mA
Current at Input Pin
±
5mA
Current at Power Supply Pin 35 mA
Junction Temperature (Note 3) 150˚C
ESD Tolerance (Note 4) 1000V
Operating Ratings(Note 1)
Temperature Range −40˚C ≤ T
J
≤
+85˚C
Supply Voltage Range 4.75V to 15.5V
Power Dissipation (Note 11)
Thermal Resistance (θ
JA
), (Note 12)
14-Pin DIP 85˚C/W
14-Pin SO 115˚C/W
DC Electrical Characteristics
Unless otherwise specified, all limits guaranteed for T
J
= 25˚C. Boldface limits apply at the temperature extremes. V
+
= 5V, V
−
= GND = 0V, V
CM
= 1.5V, V
OUT
= 2.5V, and R
L
>
1M unless otherwise specified.
Symbol Parameter Conditions Typical
(Note 5)
LMC6034I Units
Limit
(Note 6)
V
OS
Input Offset Voltage 1 9 mV
11 max
∆V
OS
/∆T Input Offset Voltage 2.3 µV/˚C
Average Drift
I
B
Input Bias Current 0.04 pA
200 max
I
OS
Input Offset Current 0.01 pA
100 max
R
IN
Input Resistance
>
1 TeraΩ
CMRR Common Mode 0V ≤ V
CM
≤ 12V 83 63 dB
Rejection Ratio V
+
= 15V 60 min
+PSRR Positive Power Supply 5V ≤ V
+
≤ 15V 83 63 dB
Rejection Ratio V
O
= 2.5V 60 min
−PSRR Negative Power Supply 0V ≤ V
−
≤ −10V 94 74 dB
Rejection Ratio 70 min
V
CM
Input Common-Mode V
+
= 5V & 15V −0.4 −0.1 V
Voltage Range For CMRR ≥ 50 dB 0 max
V
+
− 1.9 V
+
− 2.3 V
V
+
− 2.6 min
A
V
Large Signal Voltage Gain R
L
=2kΩ (Note 7) 2000 200 V/mV
Sourcing 100 min
Sinking 500 90 V/mV
40 min
R
L
= 600Ω (Note 7) 1000 100 V/mV
Sourcing 75 min
Sinking 250 50 V/mV
20 min
LMC6034
www.national.com 2
