LMZ31704
PWRGD
SENSE+
VOUT
PVIN
VIN
INH/UVLO
RT/CLK
VADJ
SS/TR
STSEL
AGND PGND
C
IN
R
SET
C
OUT
V
OUT
V
IN
R
RT
SYNC_OUT
ISHARE
LMZ31704
www.ti.com
SLVSBV8A –JUNE 2013–REVISED AUGUST 2013
4A SIMPLE SWITCHER
®
Power Module with 2.95V-17V Input and Current Sharing
in QFN Package
Check for Samples: LMZ31704
1
FEATURES
DESCRIPTION
The LMZ31704 SIMPLE SWITCHER power module
23
• Complete Integrated Power Solution Allows
is an easy-to-use integrated power solution that
Small Footprint, Low-Profile Design
combines a 4-A DC/DC converter with power
• 10mm x 10mm x 4.3mm package
MOSFETs, a shielded inductor, and passives into a
– Pin Compatible with LMZ31710 & LMZ31707
low profile, QFN package. This total power solution
allows as few as three external components and
• Efficiencies Up To 95%
eliminates the loop compensation and magnetics part
• Eco-mode™ / Light Load Efficiency (LLE)
selection process.
• Wide-Output Voltage Adjust
The 10x10x4.3 mm QFN package is easy to solder
0.6 V to 5.5 V, with 1% Reference Accuracy
onto a printed circuit board and allows a compact
• Supports Parallel Operation for Higher Current
point-of-load design. Achieves greater than 95%
efficiency and excellent power dissipation capability
• Optional Split Power Rail Allows
with a thermal impedance of 13.3°C/W. The
Input Voltages Down to 2.95 V
LMZ31704 offers the flexibility and the feature-set of
• Adjustable Switching Frequency
a discrete point-of-load design and is ideal for
(200 kHz to 1.2 MHz)
powering a wide range of ICs and systems.
• Synchronizes to an External Clock
Advanced packaging technology affords a robust and
reliable power solution compatible with standard QFN
• Provides 180° out-of-phase Clock Signal
mounting and testing techniques.
• Adjustable Slow-Start
• Output Voltage Sequencing / Tracking
Figure 1. SIMPLIFIED APPLICATION
• Power Good Output
• Programmable Undervoltage Lockout (UVLO)
• Over-Current & Over-Temperature Protection
• Pre-bias Output Start-up
• Operating Temperature Range: –40°C to 85°C
• Enhanced Thermal Performance: 13.3°C/W
• Meets EN55022 Class B Emissions
– Integrated Shielded Inductor
APPLICATIONS
• Broadband & Communications Infrastructure
• Automated Test and Medical Equipment
• Compact PCI / PCI Express / PXI Express
• DSP and FPGA Point-of-Load Applications
This integrated circuit can be damaged by ESD. Texas Instruments recommends that all integrated circuits be handled with
appropriate precautions. Failure to observe proper handling and installation procedures can cause damage.
ESD damage can range from subtle performance degradation to complete device failure. Precision integrated circuits may be more
susceptible to damage because very small parametric changes could cause the device not to meet its published specifications.
1
Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of
Texas Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.
2Eco-mode is a trademark of Texas Instruments.
3SIMPLE SWITCHER is a registered trademark of Texas Instruments.
PRODUCTION DATA information is current as of publication date.
Copyright © 2013, Texas Instruments Incorporated
Products conform to specifications per the terms of the Texas
Instruments standard warranty. Production processing does not
necessarily include testing of all parameters.
