DESCRIPTION/ORDERING INFORMATION (CONTINUED)
FUNCTION TABLES
Each Driver
(1)
MAX3243
SLLS350M – APRIL 1999 – REVISED SEPTEMBER 2008 ................................................................................................................................................
www.ti.com
Auto-powerdown can be disabled when FORCEON and FORCEOFF are high and should be done when driving
a serial mouse. With auto-powerdown enabled, the device is activated automatically when a valid signal is
applied to any receiver input. The INVALID output is used to notify the user if an RS-232 signal is present at any
receiver input. INVALID is high (valid data) if any receiver input voltage is greater than 2.7 V or less than – 2.7 V
or has been between – 0.3 V and 0.3 V for less than 30 µ s. INVALID is low (invalid data) if all receiver input
voltages are between – 0.3 V and 0.3 V for more than 30 µ s. Refer to Figure 5 for receiver input levels.
ORDERING INFORMATION
T
A
PACKAGE
(1) (2)
ORDERABLE PART NUMBER TOP-SIDE MARKING
MAX3243CDW MAX3243C
Tube of 20
MAX3243FCDW 75C3243
SOIC – DW
MAX3243CDWR MAX3243C
Reel of 1000
MAX3243FCDWR 75C3243
Tube of 50 MAX3243CDB
MAX3243C
0 ° C TO 70 ° C SSOP – DB MAX3243CDBR
Reel of 2000
MAX3243FCDB 75C3243
MAX3243CPW MAX3243
Tube of 50
MAX3243FCPW CA3243
TSSOP – PW
MAX3243CPWR MAX3243
Reel of 2000
MAX3243FCPWR CA3243
MAX3243IDW MAX3243I
Tube of 50
MAX3243FIDW 65C3243
SOIC – DW
MAX3243IDWR MAX3243I
Reel of 2000
MAX3243FIDWR 65C3243
Tube of 50 MAX3243IDB
MAX3243I
– 40 ° C TO 85 ° C SSOP – DB MAX3243IDBR
Reel of 2000
MAX3243FIDBR 65C3243
MAX3243IPW MB3243I
Tube of 50
MAX3243FIPW CB3243
TSSOP – PW
MAX3243IPWR MB3243I
Reel of 2000
MAX3243FIPWR CB3243
(1) Package drawings, thermal data, and symbolization are available at www.ti.com/packaging .
(2) For the most current package and ordering information, see the Package Option Addendum at the end of this document, or see the TI
website at www.ti.com .
INPUTS
OUTPUT
DRIVER STATUS
VALID RIN
DOUT
DIN FORCEON FORCEOFF
RS-232 LEVEL
X X L X Z Powered off
L H H X H
Normal operation with
auto-powerdown disabled
H H H X L
L L H YES H
Normal operation with
auto-powerdown enabled
H L H YES L
L L H NO Z
Power off by
auto-powerdown feature
H L H NO Z
(1) H = high level, L = low level, X = irrelevant, Z = high impedance
2 Submit Documentation Feedback Copyright © 1999 – 2008, Texas Instruments Incorporated
Product Folder Link(s): MAX3243
