General Description
The MAX3420E evaluation kit-2 (EV kit-2) provides a
proven design to evaluate the MAX3420E USB peri-
pheral controller with SPI™ interface. The EV kit-2
board is jumper-connected to an Atmel
®
ATtiny2313
microcontroller by default, but can also be connected
to any SPI master. The MAX3420E EV kit-2 adds USB
functionality to any microcontroller, microprocessor,
DSP, CPLD, FPGA, or ASIC with an SPI master inter-
face or five GPIO lines can connect to the MAX3420E
EV kit-2.
The EV kit-2 board comes with the MAX3420EECJ+
installed.
Features
Complies with USB 2.0 (Full Speed)
Custom USB Drivers Not Required
USB Powered
USB Power LED Indicator
USB Cable Included
On-Board ATtiny2313 Microcontroller
Four GPI Port-Connected Pushbuttons
Four GPO Port LED Indicators
20-Pin Signal Header to Connect the MAX3420E
to Any Microcontroller
Proven PCB Layout
Fully Assembled and Tested
Evaluates: MAX3420E
MAX3420E Evaluation Kit-2
________________________________________________________________
Maxim Integrated Products
1
19-0696; Rev 0; 12/06
Component List
For pricing, delivery, and ordering information, please contact Maxim/Dallas Direct! at
1-888-629-4642, or visit Maxim’s website at www.maxim-ic.com.
Component Suppliers
SUPPLIER PHONE WEBSITE
Murata 770-436-1300 www.murata.com
TDK 847-803-6100 www.component.tdk.com
Note: Indicate that you are using the MAX3420E when contacting
these component suppliers.
Ordering Information
PART NUMBER TYPE PC INTERFACE
MAX3420EEVKIT-2+ EV kit USB
+
Denotes a lead-free and RoHS-compliant EV kit.
DESIGNATION QTY DESCRIPTION
C1, C7 2
2.2µF ±20%, 6.3V X5R ceramic
capacitors (0603)
TDK C1608X5R0J225K or
C1608X5R0J225M
C2, C3, C6, C8 4
1µF ±20%, 6.3V X5R ceramic
capacitors (0603)
TDK C1608X5R0J105K or
C1608X5R0J105M
C4, C5 2
18pF ±5%, 50V C0G ceramic
capacitors (0402)
Murata GRM1555C1H180J
TDK C1005C0G1H180J
D1–D4 4
Green LEDs (0603)
Stanley Electric BG1111C-TR
Panasonic LNJ314G8TRA or
LNJ308G84RA
D5 1
Red LED (0603)
Panasonic LNJ208R8ARA
H1 1 Dual-row, 20-pin (2 x 10) header
H2 1 Single-row, 8-pin header
H3 1 Dual-row, 6-pin (2 x 3) header
DESIGNATION QTY DESCRIPTION
JU1–JU5,
JU10, JU11
7 3-pin headers
JU6–JU9 4 2-pin headers
P1 1
USB type B right-angle receptacle
Assmann AU-Y1007-R
R1, R2 2
33.2Ω ±1% resistors (0603)
(use lead-free parts only)
R3, R6–R9 5
150Ω ±5% resistors (0603)
(use lead-free parts only)
R4, R5 2
10kΩ ±5% resistors (0603)
(use lead-free parts only)
SW1–SW4 4
Pushbutton switches
Panasonic EQV-PHP03T
TP1, TP2, TP3 3
Mini test points (black)
Keystone Electronics 5001
U1 1
MAX3420EECJ+ USB
peripheral controller
(32-pin, 7mm x 7mm x 1.4mm,
TQFP)
SPI is a trademark of Motorola, Inc.
Atmel is a registered trademark of Atmel Corp.
