Evaluates: MAX3420E
MAX3420E Evaluation Kit-2
_______________________________________________________________________________________ 5
Table 7. Header H1 Pin Description
PIN NAME DESCRIPTION
1 GPX GPX line
2 CONINT Interrupt (INT) Line (Note 1)
3 CONMISO Master In Slave Out (MISO) Line (Note 2)
4 CONMOSI Master Out Slave In (MOSI) Line (Note 3)
5 CONSCLK Serial Clock (SCLK) Line (Note 4)
6 CONSS Active-Low Slave Select (SS) Line (Note 5)
7 GPO3 General-Purpose Output 3 (Note 6)
8 RES Active-Low Reset Line
9V
L
Logic-Voltage-Supply Line
10 GPO2 General-Purpose Output 2 (Note 6)
11 GND Ground
12 GND Ground
13 GPO0 General-Purpose Output 0 (Note 6)
14 GPO1 General-Purpose Output 1 (Note 6)
15 GPI2 General-Purpose Input 2 (Note 7)
16 GPI3 General-Purpose Input 3 (Note 7)
17 GPI0 General-Purpose Input 0 (Note 7)
18 GPI1 General-Purpose Input 1 (Note 7)
19 3.3V 3.3V EV Kit-2 Board Supply
20 GND Ground
Note 1: If jumper JU1 is in the 2-3 position.
Note 2: If jumper JU4 is in the 2-3 position.
Note 3: If jumper JU3 is in the 2-3 position.
Note 4: If jumper JU5 is in the 2-3 position.
Note 5: If jumper JU2 is in the 2-3 position.
Note 6: Also connected to an LED through a current-limiting resistor if the respective jumper is in place.
Note 7: General-purpose inputs are internally pulled up to VL, so external pullups are not required.
