PC817X*NIP1B
2/10
1. Application
This specification applies to the outline and characteristics of photocoupler Model No. PC817series(Lead-Free Type).
2. Outline Refer to the attached sheet, page 4.
3. Ratings and characteristics Refer to the attached sheet, page 5, 6.
4. Reliability Refer to the attached sheet, page 7.
5. Outgoing inspection Refer to the attached sheet, page 8.
6. Supplement
6.1 Isolation voltage shall be measured in the following method.
(1) Short between anode and cathode on the primary side and between collector and emitter on the secondary side.
(2) The dielectric withstanding tester with zero-cross circuit shall be used.
(3) The wave form of applied voltage shall be a sine wave.
(It is recommended that the isolation voltage be measured in insulation oil.)
6.2 Package specifications Refer to the attached sheet, page 9, 10.
6.3 Business dealing name ("○" mark indicates business dealing name of ordered product)
Ordered product Business dealing name Rank mark Ic (mA)
PC817XNNIP1B
with or without
2.5 to 30.0
PC817X1NIP1B
A
4.0 to 8.0
PC817X2NIP1B
B
6.5 to 13.0
PC817X3NIP1B
C
10.0 to 20.0
PC817X4NIP1B
D
15.0 to 30.0
PC817X5NIP1B
A or B
4.0 to 13.0
PC817X6NIP1B
B or C
6.5 to 20.0
PC817X7NIP1B
C or D
10.0 to 30.0
PC817X8NIP1B
A, B or C
4.0 to 20.0
PC817X9NIP1B
B, C or D
6.5 to 30.0
PC817X0NIP1B
A, B, C or D
4.0 to 30.0
6.4 This Model is approved by UL. (Under preparation).
Approved Model No. : PC817
UL file No. : E64380
6.5 This Model is approved by CSA. (Under preparation).
Approved Model No. : PC817
CSA approved mark " " shall be indicated on minimum unit package.
6.6 This product is not designed against irradiation.
This product is assembled with electrical input and output.
This product incorporates non-coherent light emitting diode.
Test conditions
I
F
=5mA
V
CE
=5V
Ta=25℃
REFERENCE
