corcom.com
Corcom Filter ProductsTE Connectivity
SERIES
PERFORMANCE
Approvals
Features
ELECTRICAL PARAMETERS
Max. voltage
Current Ratings
Leakage current each Line to Ground
@ 120VAC 60Hz / 250VAC 50Hz
Electrical Setup
Mounting features
Termination inputs
Termination outputs
MECHANICAL PARAMETERS
TYPICAL APPLICATIONS
FILTER TYPE
B Series
General purpose RFI Filters for high
impedance load / low current
•General purpose
•Wide variety of termination options
•Meets low leakage current
requirements of VDE portable
equipment and non-patient medical
equipment
250 VAC
1, 2, 3, 5, 10, 20 or 30A
VB Models: .4 mA / .7 mA
EB Models: .21 mA / .36 mA
Single stage
Screw mounting
.25 [6.3] spade terminals,
8-32 terminal bolt & nut or
wire leads
.25 [6.3] spade terminals,
8-32 terminal bolt & nut or
wire leads
Wide band RFI suppression
for applications requiring low
attenuation including:
•H VAC
•TV / Audio / Video
•Computing & accessories
•Home appliances
•Medical equipment
•Battery charging systems
•Exercise equipment
K Series
General Purpose
250 VAC
1, 2, 3, 5, 10, 20, 30, 40 or 60A
VK Models: .5 mA / 1.0 mA
EK Models: .21 mA / .36 mA
Single stage
Screw mounting (flange or panel)
.25 [6.3] spade terminals,
8-32 terminal bolt & nut,
wire leads or IEC 60320-1 C14 or C20
.25 [6.3] spade terminals,
8-32 terminal bolt & nut or
wire leads
DK Series
250 VAC
1, 3, 6, 10 or 20A
VDK Models: .4 mA / .7 mA
EDK Models: .22 mA / .38 mA
Dual stage
Screw mounting
.25 [6.3] spade terminals,
8-32 terminal bolt & nut or
wire leads
.25 [6.3] spade terminals,
8-32 terminal bolt & nut or
wire leads
Universal filter for applications
requiring improved attenuation
including:
•TV / Audio / Video
•Computing & accessories
•Home appliances
•Medical equipment
•Gaming machines
•Exercise equipment
UL / CSA / VDE
General purpose RFI power line
filters for high impedance loads
•Well suited to applications
where pulsed, continuous and/
or intermittent RFI interference is
present
•EK models meet the very low
leakage current requirements for
VDE portable equipment and non-
patient care medical equipment
•Available with ground line inductor
(choke)
UL / CSA / VDE
Enhanced dierential mode
performance K Series RFI line filters
•Higher performance line to line
attenuation than the K Series
•E version meets the very low
leakage current requirements for
VDE portable equipment and non-
patient care medical equipment
•V version features same high
performance with more
cost-eective design
UL / CSA / VDE
POWER LINE FILTERS
Universal filter for applications
requiring mid-range attenuation
including:
•TV / Audio / Video
•Computing & accessories
•Home appliances
•Medical equipment
•Gaming machines
•Exercise equipment
•Test measurement equipment
