Corcom Filter ProductsTE Connectivity
R Series
Two-stage general purpose RFI
power line filter
•Dual T section RFI filter provides
premium performance
•Well suited for low impedance
loads where noisy RFI
environments are present
•Controls pulsed, continuous and/or
intermittent interference
•ER model oers low leakage
current without deterioration of
insertion loss
250 VAC
1, 2, 3, 5, 10 or 20A
VR Models: .4 mA / .7 mA
ER Models: .21 mA / .36 mA
Single stage
Screw mounting (flange or panel)
.25 [6.3] spade terminals,
8-32 terminal bolt & nut,
wire leads or IEC 60320-1 C14
.25 [6.3] spade terminals,
8-32 terminal bolt & nut or
wire leads
EBP, EDP, EOP Series
General Purpose
250 VAC
1, 3, 6 or 10A
EDP/EOP Models: .22 mA / .38 mA
EBP Models: .13 mA / .21 mA
Single stage
PC board pins
PCB pins .025 [.635] square
PCB pins .025 [.635] square
Designed for PCB mounting for a
wide range of applications including:
•Gaming machines
•Cash terminals
•Oce equipment
•Small consumer electronics
•TV / Audio / Video
•Computing & accessories
WG Series
Wide Range Performance
250 VAC
16A
A, B & C Models: .76 mA / 1.27 mA
D, E & F Models: .10 mA / .20 mA
Single stage
Screw-in mounting stud
.25 [6.3] spade terminals,
wire leads or
RAST 5 header interface
.25 [6.3] spade terminals,
wire leads or
RAST 5 header interface
Specially designed for the white
goods / appliance market. Oers
wide band RFI suppression for many
applications including:
•Washing machines / dryers
•Dishwashers
•Refrigerators & freezers
•Coee Machines
•Hand held appliances & tools
•Ovens & ranges
UL / CSA / VDE
PC board mountable general
purpose RFI filters
•General purpose
•Low leakage current
•Cost-eective
•Compact size
•EDP model features enhanced
dierential mode performance
•EBP model features compact size
(less than 1” square)
UL / CSA / VDE
High performance, low cost filter
ideal for appliance equipment
•Cost eective
•Tubular design
•WGD, WGE and WGF versions
designed to comply with leakage
current requirements for appliances
which may be easily moved from
one place to another
•Available in a variety of styles
UL / CSA / VDE
X, Y & Z Series
250 VAC
1, 2, 3, 4 or 6A
.3 mA / .5 mA
Single stage
Screw mount or PC board pins
.25 [6.3] spade terminals or
PCB pins .065[1.65] diagonal
.25 [6.3] spade terminals or
PCB pins .065[1.65] diagonal
RFI filter designed to bring most
digital equipment (including those
with switching power supplies) into
compliance with EN55022, Level
A or B and FCC Part 15J, Class B
conducted emission limits. Ideal for
all applications with limited space
including:
•Switching Power Supplies
•Industrial single phase applications
Chassis or PC Board Mountable
Power Line Filters for Emission
Control
•Compact chassis or PC board
mountable
•Three levels of performance
•Complete filtering solution in
minimal size
•X Series for FCC Part 15J, Class B
•Y Series for EN55022, Level A
•Z Series for EN55022, Level B
•Medical version available in the
HZ Series
UL / CSA / VDE
POWER LINE FILTERS (Continued)
Universal filter for applications with
low impedance loads including:
•Motors
•Semiconductor actuators
•Home appliances
•Gaming machines
•Exercise equipment
•Security systems
•Industrial equipment & controls
