corcom.com
Corcom Filter ProductsTE Connectivity
SK Series
High Performance K Series RFI Line
Filters for SMPS Emission Control
•Designed to reduce conducted
noise to acceptable limits for
equipment that must comply with
FCC / EN specifications
•Utilizes significantly higher element
values than the general purpose K
Series
•ESK6C and VSK6C incorporate
separate ground circuit inductor
RK Series EMC Series
UL / CSA / VDE
High Performance Compact Power
Line Filter
•Compact
•Single stage
•Significant dierential mode
performance
•Suitable for industrial machinery
•Low input leakage current makes it
suitable for portable equipment
UL / CSA / VDE
Compact and Cost-eective Dual
Stage RFI Power Line Filters
•Compact dual stage filter series
•Current rating up to 30A
•High dierential mode attenuation
in the lower frequency range
•High common mode performance
•Ideal for switching mode power
supplies
UL / CSA / VDE
IK Series
Wide Range Performance
Single and 2-phase RFI Filters for
Industrial Applications
•Excellent performance for
applications with high interference
levels
•Designed for single or two-phase
applications
•Available touch safe terminals
provide easy connections and
prevent inadvertent contact
POWER LINE FILTERS (Continued)
250 VAC
3, 6, 10, 20, 30 & 40A
.4 mA / .7 mA
(3-10A VSK models)
.21 mA / .36 mA (3-10A ESK models)
.75 mA / 1.25 mA (3-10A VSK models)
.3 mA / .5 mA (3-10A ESK models)
Single stage
Screw mounting (flange or panel)
.25 [6.3] spade terminals,
terminal bolt & nut,
wire leads or IEC 60320-1 C14
.25 [6.3] spade terminals,
terminal bolt & nut or
wire leads
Universal filter for consumer
electronic applications requiring
a premium range of attenuation
including:
•TV / Audio / Video
•Computing & accessories
•Home appliances
•Medical equipment
•Industrial equipment & controls
•Exercise equipment
250 VAC
3, 6, 10, 15 & 20A
.16 mA / .26 mA
Single stage
Screw mounting
.25 [6.3] spade terminals
.25 [6.3] spade terminals
Wide band RFI suppression
for applications requiring high
attenuation level including:
•Consumer electronics
•Industrial machinery equipment
•Small machine tools
•Home appliances
•Power supplies
250 VAC
3, 6, 10, 15, 20 & 30A
.21 mA / .43 mA
(3-10A models)
.73 mA / 1.52 mA (15-30A models)
Dual stage
Screw mounting
.25 [6.3] spade terminals,
8-32 terminal bolt & nut or
wire leads
.25 [6.3] spade terminals,
8-32 terminal bolt & nut or
wire leads
Wide band RFI suppression
for applications requiring high
attenuation levels including:
•Consumer electronics
•Single phase industrial equipment
•Inverters
•Switching power supplies
500 VAC MAX. Line to Ground
1, 6, 16, 35, 50 & 80A
.06 mA / 1.2 mA*
(1 & 6A models)
1.7 mA / 3.2 mA* (16 - 50A models)
5.2 mA / 9.9 mA* (80A model)
* 1A @ 289 VAC, 16-80A @ 277 VAC 50Hz
Dual stage (6-80A models)
Dual stage + ground choke (1A only)
Screw mounting
.25 [6.3] spade terminals or
DIN type terminal block and bolt/nut
.25 [6.3] spade terminals,
wire leads or
DIN type terminal block and bolt/nut
Wide band RFI filter for small to
medium sized industrial equipment,
power converters and variable speed
motors. Provides suppression of
industrial 2-phase applications with
high RFI emissions including:
•Transportation vehicles
•Site applications
•Small construction machinery
