PIC16(L)F1516/7/8/9
DS40001452F-page 2 2010-2016 Microchip Technology Inc.
• Master Synchronous Serial Port (MSSP) with SPI
and I
2
C with:
- 7-bit address masking
- SMBus/PMBus
TM
compatibility
• Enhanced Universal Synchronous Asynchronous
Receiver Transmitter (EUSART) module:
- RS-232, RS-485 and LIN compatible
- Auto-Baud Detect
- Auto-wake-up on start
PIC16(L)F151X/152X Family Types
Device
Data Sheet Index
Program Memory
Flash (words)
Data SRAM
(bytes)
High Endurance Flash
(bytes)
I/O’s
(2)
ADC
Timers
(8/16-bit)
EUSART
MSSP (I
2
C/SPI)
CCP
Debug
(1)
XLP
10-bit (ch)
Advanced Control
PIC16(L)F1512 (1) 2048 128 128 25 17 Y 2/1 1 1 2 I Y
PIC16(L)F1513 (1) 4096 256 128 25 17 Y 2/1 1 1 2 I Y
PIC16(L)F1516 (2) 8192 512 128 25 17 N 2/1 1 1 2 I Y
PIC16(L)F1517 (2) 8192 512 128 36 28 N 2/1 1 1 2 I Y
PIC16(L)F1518 (2) 16384 1024 128 25 17 N 2/1 1 1 2 I Y
PIC16(L)F1519 (2) 16384 1024 128 36 28 N 2/1 1 1 2 I Y
PIC16(L)F1526 (3) 8192 768 128 54 30 N 6/3 2 2 10 I Y
PIC16(L)F1527 (3) 16384 1536 128 54 30 N 6/3 2 2 10 I Y
Note 1: I - Debugging, Integrated on Chip; H - Debugging, available using Debug Header.
2: One pin is input-only.
Data Sheet Index: (Unshaded devices are described in this document.)
1: DS40001624 PIC16(L)F1512/13 Data Sheet, 28-Pin Flash, 8-bit Microcontrollers.
2: DS40001452 PIC16(L)F1516/7/8/9 Data Sheet, 28/40/44-Pin Flash, 8-bit MCUs.
3: DS40001458 PIC16(L)F1526/27 Data Sheet, 64-Pin Flash, 8-bit MCUs.
Note: For other small form-factor package availability and marking information, please visit
http://www.microchip.com/packaging or contact your local sales office.
