2016 Microchip Technology Inc. DS80000698B-page 5
PIC16(L)F18854
2. Module: Complementary Waveform
Generator (CWG)
In Register 20-9: CWGxISM, IS<3:0> has
incorrect descriptions for its bit selections. The
correct description is below:
bit 7-4 Unimplemented: Read as ‘0’
bit 3-0 IS<3:0>: CWGx Input Selection bits
1111 = LC4_out
1110 = LC3_out
1101 = LC2_out
1100 = LC1_out
1011 = DSM_out
1010 = C2OUT_sync
1001 = C1OUT_sync
1000 = NCO1_out
0111 = PWM7_out
0110 = PWM6_out
0101 = CCP5_out
0100 = CCP4_out
0011 = CCP3_out
0010 = CCP2_out
0001 = CCP1_out
0000 = CWGxIN PPS
3. Module: Signal Measurement Timer
(SMT)
The description for the Counter mode of the SMT
given in 32.6.9 contains incorrect information,
given the setup described earlier in the chapter.
The corrected text is as follows:
This mode increments the timer on each pulse of
the SMTx_signal input. This mode is
asynchronous to the SMT clock and uses the
SMTx_signal as a time source. The SMTxCPW
register will be updated with the current SMTxTMR
value on the falling edge of the SMTxWIN input.
