2008-2013 Microchip Technology Inc. DS80000425K-page 1
PIC18F24K20/25K20/44K20/45K20
The PIC18F24K20/25K20/44K20/45K20 devices that
you have received conform functionally to the current
Device Data Sheet (DS41303G), except for the
anomalies described in this document.
The silicon issues discussed in the following pages are
for silicon revisions with the Device and Revision IDs
listed in Table 1. The silicon issues are summarized in
Table 2.
The errata described in this document will be addressed
in future revisions of the PIC18F24K20/25K20/44K20/
45K20 silicon.
Data Sheet clarifications and corrections start on page
12, following the discussion of silicon issues.
The silicon revision level can be identified using the
current version of MPLAB
®
IDE and Microchip’s pro-
grammers, debuggers, and emulation tools, which are
available at the Microchip corporate web site
(www.microchip.com).
For example, to identify the silicon revision level
using MPLAB IDE in conjunction with a hardware
debugger:
1. Using the appropriate interface, connect the
device to the hardware debugger.
2. Open an MPLAB IDE project.
3. Configure the MPLAB IDE project for the
appropriate device and hardware debugger.
4. Based on the version of MPLAB IDE you are
using, do one of the following:
a) For MPLAB IDE 8, select Programmer >
Reconnect.
b) For MPLAB X IDE, select Window > Dash-
board and click the Refresh Debug Tool
Status icon ( ).
5. Depending on the development tool used, the
part number and Device Revision ID value
appear in the Output window.
The DEVREV values for the various PIC18F24K20/
25K20/44K20/45K20 silicon revisions are shown in
Table 1.
Note: This document summarizes all silicon
errata issues from all revisions of silicon,
previous as well as current. Only the
issues indicated in the last column of
Table 2 apply to the current silicon revi-
sion (AF).
Note: If you are unable to extract the silicon
revision level, please contact your local
Microchip sales office for assistance.
TABLE 1: SILICON DEVREV VALUES
Part Number Device ID
(1)
(11-bit)
Revision ID for Silicon Revision
(2)
(5-bit)
A4 A7 A9 AB A4 A7 A8 AE AF
PIC18F24K20 105h
0xA 0xC 0xE 0x11 0x16 0x18 0x19 0x1B 0x1C
PIC18F25K20 103h
0xA 0xC 0xE 0x11
0x16 0x18 0x19 0x1B 0x1C
PIC18F44K20 104h
0xA 0xC 0xE 0x11
0x16 0x18 0x19 0x1B 0x1C
PIC18F45K20 102h
0xA 0xC 0xE 0x11
0x16 0x18 0x19 0x1B 0x1C
Note 1: The Device IDs (DEVID and DEVREV) are located at the last two implemented addresses of configuration
memory space. They are shown in hexadecimal in the format “DEVID:DEVREV”.
2: Refer to the “PIC18F2XK20/4XK20 Flash Memory Programming Specification” (DS41297) for detailed
information on Device and Revision IDs for your specific device.
3: Shaded cells in this table indicate older device revisions that are no longer in production.
PIC18F24K20/25K20/44K20/45K20
Silicon Errata and Data Sheet Clarification
