TMP75B
ZHCSCD2B –APRIL 2014–REVISED AUGUST 2014
www.ti.com.cn
6 Specifications
6.1 Absolute Maximum Ratings
over operating free-air temperature range (unless otherwise noted)
(1)
MIN MAX UNIT
Supply voltage, V
S
4 V
SDA, SCL, ALERT, A2, A1 -0.3 4 V
Input voltage
A0 -0.3 (V
S
) + 0.3 V
Sink current SDA, ALERT 10 mA
Operating junction temperature -55 150 °C
(1) Stresses beyond those listed under Absolute Maximum Ratings may cause permanent damage to the device. These are stress ratings
only, which do not imply functional operation of the device at these or any other conditions beyond those indicated under Recommended
Operating Conditions. Exposure to absolute-maximum-rated conditions for extended periods may affect device reliability.
6.2 Handling Ratings
MIN MAX UNIT
T
stg
Storage temperature range -60 150 °C
Human body model (HBM), per ANSI/ESDA/JEDEC JS-001, all pins
(1)
–2000 2000
Electrostatic
V
(ESD)
V
discharge
Charged device model (CDM), per JEDEC specification JESD22-C101, all pins
(2)
–1000 1000
(1) JEDEC document JEP155 states that 500-V HBM allows safe manufacturing with a standard ESD control process.
(2) JEDEC document JEP157 states that 250-V CDM allows safe manufacturing with a standard ESD control process.
6.3 Recommended Operating Conditions
over operating free-air temperature range (unless otherwise noted)
MIN NOM MAX UNIT
Supply voltage 1.4 1.8 3.6 V
Operating free-air temperature, T
A
-55 125 °C
6.4 Thermal Information
TMP75B
THERMAL METRIC
(1)
D (SOIC) DGK (VSSOP) UNIT
8 PINS 8 PINS
R
θJA
Junction-to-ambient thermal resistance 125.4 188.1
R
θJC(top)
Junction-to-case (top) thermal resistance 71.5 79.1
R
θJB
Junction-to-board thermal resistance 65.8 109.6
°C/W
ψ
JT
Junction-to-top characterization parameter 21.1 15.3
ψ
JB
Junction-to-board characterization parameter 65.3 108
R
θJC(bot)
Junction-to-case (bottom) thermal resistance N/A N/A
(1) For more information about traditional and new thermal metrics, see the IC Package Thermal Metrics application report, SPRA953.
4 Copyright © 2014, Texas Instruments Incorporated
