Silicon Errata
SPRZ234R–December 2005– Revised January 2012
TMS320C6455/54 Digital Signal Processor
Silicon Revisions 3.1, 2.1, 2.0, 1.1
1 Introduction
This document describes the known exceptions to the functional specifications for the TMS320C6455/54
digital signal processors; see the TMS320C6455 Fixed-Point Digital Signal Processor data manual
(literature number SPRS276) and the TMS320C6454 Fixed-Point Digital Signal Processor data manual
(literature number SPRS311).
For additional information, see the TMS320C6000 DSP Peripherals Overview Reference Guide (literature
number SPRU190).
The advisory numbers in the document are not sequential. Some advisory numbers have been moved to
the next revision. When items are moved, the remaining advisory numbers are not resequenced.
This document also contains "Usage Notes." Usage Notes highlight and describe particular situations
where the device's behavior may not match presumed or documented behavior. This may include
behaviors that affect device performance or functional correctness. These notes will be incorporated into
future documentation updates for the device (such as the device-specific data manual), and the behaviors
they describe will not be altered in future silicon revisions.
1.1 Device and Development-Support Tool Nomenclature
To designate the stages in the product development cycle, TI assigns prefixes to the part numbers of all
DSP devices and support tools. Each DSP commercial family member has one of three prefixes: TMX,
TMP, or TMS (e.g., TMS320C6455CTZ). Texas Instruments recommends two of three possible prefix
designators for its support tools: TMDX and TMDS. These prefixes represent evolutionary stages of
product development from engineering prototypes (TMX/TMDX) through fully qualified production
devices/tools (TMS/TMDS).
Device development evolutionary flow:
TMX Experimental device that is not necessarily representative of the final device's electrical
specifications
TMP Final silicon die that conforms to the device's electrical specifications but has not
completed quality and reliability verification
TMS Fully qualified production device
Support tool development evolutionary flow:
TMDX Development-support product that has not yet completed Texas Instruments internal
qualification testing
TMDS Fully qualified development-support product
TMX and TMP devices and TMDX development-support tools are shipped against the following
disclaimer:
"Developmental product is intended for internal evaluation purposes."
TMS devices and TMDS development-support tools have been characterized fully, and the quality and
reliability of the device have been demonstrated fully. TI's standard warranty applies.
All trademarks are the property of their respective owners.
5
SPRZ234R– December 2005– Revised January 2012TMS320C6455/54 Digital Signal Processor— Silicon Revisions 3.1, 2.1, 2.0, 1.1
Submit Documentation Feedback
Copyright © 2005–2012, Texas Instruments Incorporated
