C6748BZWT
TMS320
21
Pkg Pin 1 location
www.ti.com
Introduction
1.2 Revision Identification
The silicon revision is identified by a code marked on the package. Please see the figure Device
nomenclature in the data manuals Packaging information section for coding details. Table 1 describes the
relationship between device revision code and silicon revision.
Table 1. C6748 Device Revision Codes
DEVICE REVISION SILICON
COMMENTS
CODE (xx) REVISION
E 2.3
Silicon Revision 2.1 can be differentiated from Revision
2.0 by a top side '21' marking on the package. See
B 2.1 Figure 1 for details.
Additionally the ROM ID code may be used to
distinguish Revision 2.1 from Revision 2.0
B 2.0 -
A 1.1 -
(blank) 1.0 -
Figure 1. Device Markings
3
SPRZ303H–June 2009–Revised March 2014 TMS320C6748 Fixed- and Floating-Point DSP Silicon Revisions 2.3, 2.1, 2.0,
1.1 and 1.0
Submit Documentation Feedback
Copyright © 2009–2014, Texas Instruments Incorporated
