Copyright © 2013-2016 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree
®
, XLamp
®
and EasyWhite
®
are registered trademarks and the Cree logo is a
trademark of Cree, Inc. ENERGY STAR
®
is a registered trademark of the U.S. Environmental Protection Agency. Other trademarks, product, and company names are the property of their respective owners and
do not imply specic product and/or vendor endorsement, sponsorship or association. For product specications, please see the data sheets available at www.cree.com. For warranty information, please
contact Cree Sales at sales@cree.com.
5
XLAMP
®
CXA1512 LED RETAIL TRACK LIGHT REFERENCE DESIGN
target area, with minimal losses within the xture. As a result, a lumens-for-lumens comparison between an CXA1512 LED and a CMH
lamp is only partially relevant.
Table 7 shows the design goals for this project.
Table 7: CXA1512 retail track light design goals
Characteristic Unit Minimum Goal Target Goal
Light output lm 1,200 > 1,200
Light intensity - CBCP cd 10,000 > 10,000
Beam angle - FWHM degrees 13 13
Luminaire efcacy lm/W 70 > 70
CCT K 3000 3000
CRI 100-point scale 80 > 80
Power W 18 < 18
3.
We used Cree’s Product Characterization Tool (PCT) tool to determine the drive current for the design. Figure 1 shows basic electrical data
and optical output from the PCT. We estimated 90% optical efciency, 88% driver efciency and a solder-point temperature (T
SP
) of 70°C.
Figure 1:
The PCT output shows that, at 400mA, a single XLamp CXA1512 LED produces the desired lumen output and efcacy.
Proper thermal management is a key component of any successful LED-based lamp or luminaire design. Operating at 17W of power in
this retail track light design, the XLamp CXA1512 LED requires a heat sink to dissipate this thermal load. The heat sink in this design must
Compare:
12 14 11 10 4
System:
1,200 90% 88%
Model 4
Model 1 Model 1
Flux 7 1290.0
Flux 1
0.0
Flux 1
Price -$ 2.0 70
Price -$ 1.0 25 Price -$
ΔVf
0.000 Multiple
1
ΔVf
0.000 Multiple
1
ΔVf
0.000
SYS lm tot
SYS lm/W
SYS W
SYS # LED
0.360 2308.8 76.4 30.209 2
#N/A #N/A #N/A #N/A #N/A #N/A
0.370 2354.9 75.6 31.146 2
#N/A #N/A #N/A #N/A #N/A #N/A
0.380 1200.4 74.8 16.044 1
#N/A #N/A #N/A #N/A #N/A #N/A
0.390 1222.7 74 16.517 1
#N/A #N/A #N/A #N/A #N/A #N/A
0.400 1244.7 73.3 16.991 1
#N/A #N/A #N/A #N/A #N/A #N/A
0.410 1266.4 72.5 17.467 1
#N/A #N/A #N/A #N/A #N/A #N/A
0.420 1287.7 71.8 17.945 1
#N/A #N/A #N/A #N/A #N/A #N/A
0.430 1308.7 71 18.424 1
#N/A #N/A #N/A #N/A #N/A #N/A
0.440
1329.5 70.3 18.906 1 #N/A #N/A #N/A #N/A #N/A #N/A
LED 2
LED 3
Current (A)
Current Display Range:
Optical Efficiency:
Electrical Efficiency:
Target Lumens :
LED 1
Cree XLamp CXA1512 LES 9r {EZW}
K4 [1290]
0.300A - 0.700A
(none)
(none)
SYS lm tot
SYS lm/W
SYS W
SYS # LED
Tsp (ºC)
Tj (ºC)
x1
x1
