6 | Motor Drive and Control Solutions Texas Instruments
Microcontrollers for control
TM4C ARM
®
Cortex
®
-M core based high-performance MCUs
Evaluation kit
The TM4C123G aunchPad™ evaluation kit is a low-cost evaluation platform for
ARM
®
Cortex
®
-M4F-based MCUs from Texas Instruments. The price is only US
$12.99. The design of the TM4C123G LaunchPad highlights the TM4C123GH6PM
MCU with a USB 2.0 device interface and hibernation module.
The EK-TM4C123GXL also features programmable user buttons and an RGB LED
for custom applications. The stackable headers of the TM4C123G LaunchPad
BoosterPack™ XL Interface make it easy and simple to expand the functionality
of the TM4C123G LaunchPad when interfacing to other peripherals with Texas
Instruments’ BoosterPacks.
The TM4C1294 Connected LaunchPad evaluation kit is a low-cost development
platform for ARM Cortex-M4F-based MCUs. The price is only US $19.99. The
Connected LaunchPad design highlights the TM4C1294NCPDT MCU with its
on-chip 10/100 Ethernet MAC and PHY, USB 2.0, hibernation module, motion
control pulse-width modulation and a multitude of simultaneous serial connectivity.
The TM4C129E Crypto Connected LaunchPad evaluation kit is a low-cost plat-
form for ARM Cortex-M4-based MCUs. The price is US $24.99. The kit design
highlights the TM4C129ENCPDT MCU with on-chip crypto acceleration hardware,
10/100 Ethernet MAC + PHY, USB 2.0, hibernation module, motion control pulse-
width modulation and a multitude of simultaneous serial connectivity.
Development kits
The TM4C Series TM4C123G ARM Cortex M4F-based MCU development kit
is a compact and versatile evaluation platform for the TM4C123G ARM Cortex-M4-
based MCU. The development kit design highlights the TM4C123G MCU integrated
USB 2.0 on-the-go/host/device interface, CAN, precision analog, sensor hub and
low-power capabilities. The development kit features a TM4C123GH6PGE MCU
in a 144-LQFP package, a color OLED display, USB OTG connector, a microSD
card slot, a coin-cell battery for the low-power hibernate mode, a CAN transceiver,
a temperature sensor, a nine-axis sensor for motion tracking and easy-access
through-holes to all of the available device signals.
The TM4C129x Connected LaunchPad evaluation kit is a versatile and feature-rich
engineering platform that highlights the 120 Hz TM4C129XNCZAD ARM Cortex-M4
based microcontroller, including an integrated 10/100 Ethernet MAC + PHY as well
as many other key features such as color LCD, USB 2.0 port, etc.
The kit also includes an in-circuit debug interface (ICDI) and extensive software
offerings that provide libraries for key functions, source code examples and
important utilities to allow professional engineers to build and debug C code-
based solutions quickly and efficiently in one of the several supported integrated
development environments (IDEs), including Keil™, Mentor™ Embedded, IAR
Systems
®
and Code Composer Studio™.
SLYB165H Motor Spin Guide.indd 6 11/11/15 12:26 PM
