Overview
www.ti.com
List of Tables
1 TMP112EVM Kit Contents.................................................................................................. 2
2 Related Documentation..................................................................................................... 4
3 Signal Definition of H1 on the TMP112EVM Board ..................................................................... 5
4 Bill of Materials ............................................................................................................. 20
1 Overview
The TMP112 is a digital output temperature sensor capable of reading temperatures to 12 bits of
resolution. The TMP112 uses a two-wire, I
2
C™ and SMBus™ interface that allows up to four devices on
one bus. The TMP112 is ideal for extended temperature measurement, and is also specified to operate
between –40°C and 125°C. The TMP112EVM is a platform for evaluating the performance of the TMP112
under various signal, reference, and supply conditions.
This document gives a general overview of the TMP112EVM and provides a general description of the
features and functions to be considered while using this evaluation module.
1.1 TMP112EVM Kit Contents
Table 1 summarizes the contents of the TMP112EVM kit. Figure 1 illustrates all of the included hardware.
Contact the Texas Instruments Product Information Center nearest you if any component is missing. TI
highly recommends that you also check the TMP112 product folder on the TI web site at www.ti.com to
verify that you have the latest versions of the related software.
Table 1. TMP112EVM Kit Contents
Item Quantity
TMP112EVM PCB test board 1
SM-USB-DIG platform PCB 1
USB extender cable 1
10-pin connector ribbon cable 1
SMBus is a trademark of Intel Corporation.
Microsoft, Windows are registered trademarks of Microsoft Corporation.
I
2
C is a trademark of NXP Semiconductors.
WinZIP is a registered trademark of WinZip International LLC.
All other trademarks are the property of their respective owners.
2
TMP112EVM Evaluation Board and Software Tutorial SBOU144–August 2014
Submit Documentation Feedback
Copyright © 2014, Texas Instruments Incorporated
