3
7792B–AVR–05/09
ATtiny87/ATtiny167 Automotive
Output High Voltage
(4)
,
I/O pin except RESET
I
OH
= –10 mA, V
CC
= 5V V
OH
4.0 V
Input Leakage
Current I/O Pin
V
CC
= 5.5V, pin low
(absolute value)
I
IL
1µA
Input Leakage
Current I/O Pin
V
CC
= 5.5V, pin high
(absolute value)
I
IH
1µA
Reset Pull-up Resistor R
RST
35 65 kΩ
I/O Pin Pull-up Resistor R
PU
20 50 kΩ
Power Supply Current
Active mode
16 MHz, Vcc = 5V I
CC
10 15 mA
8 MHz, Vcc = 5V I
CC
5.5 8.0 mA
8 MHz, Vcc = 3V I
CC
2.8 4.0 mA
4 MHz, Vcc = 3V I
CC
1.8 3.0 mA
Power Supply Current
Idle mode
16 MHz, Vcc = 5V I
CC
3.5 6.0 mA
8 MHz, Vcc = 5V I
CC
1.8 3.0 mA
8 MHz, Vcc = 3V I
CC
1.0 2.0 mA
4 MHz, Vcc = 3V I
CC
0.5 1.0 mA
Power Supply Current
Power-down mode
WDT enabled, Vcc = 5V I
CC
7 150 µA
WDT disabled, Vcc = 5V I
CC
0.18 150 µA
WDT enabled, Vcc = 3V I
CC
5 150 µA
WDT disabled, Vcc = 3V I
CC
0.15 100 µA
Analog Comparator
Input Leakage Current
V
CC
= 5V
V
in
= V
CC
/2
I
ACLK
–50 +50 nA
Analog Comparator
Propagation Delay
V
CC
= 4.0V t
ACPD
180 ns
1.2 DC Characteristics (Continued)
T
A
= –40°C to +150°C, V
CC
= 4.5V to 5.5V (unless otherwise noted) (Continued)
Parameters Test Conditions Symbol Min. Typ. Max. Unit
Notes: 1. “Max” means the highest value where the pin is guaranteed to be read as low
2. “Min” means the lowest value where the pin is guaranteed to be read as high
3. Although each I/O port can sink more than the test conditions (20 mA at V
CC
= 5V) under steady state conditions (non-tran-
sient), the following must be observed:
1] The sum of all IOL, for all ports, should not exceed 400 mA.
2] The sum of all IOL, for ports C0 - C5, should not exceed 200 mA.
3] The sum of all IOL, for ports C6, D0 - D4, should not exceed 300 mA.
4] The sum of all IOL, for ports B0 - B7, D5 - D7, should not exceed 300 mA.
If IOL exceeds the test condition, VOL may exceed the related specification. Pins are not guaranteed to sink current greater
than the listed test condition.
4. For temperature range +125°C to +150°C only. For –40°C to +125°C, refer to ATtiny167automotive datasheet.
