4
7792B–AVR–05/09
ATtiny87/ATtiny167 Automotive
1.4 Memory Endurance
EEPROM endurance: 50,000 Write/Erase cycles.
Flash endurance: 10,000 Write/Erase cycles.
1.3 ADC Characteristics
T
A
= –40°C to +150°C, V
CC
= 4.5V to 5.5V (unless otherwise noted)
Parameters Test Conditions Symbol Min. Typ. Max. Unit
Resolution Single ended 10 Bit
Absolute accuracy
Vcc = 4V, VRef = 4V,
ADC clock = 200 kHz
TUE 2.0 3.5 LSB
Integral non linearity
Vcc = 4V, VRef = 4V,
ADC clock = 200 kHz
INL 0.6 2.0 LSB
Differential non linearity
Vcc = 4V, VRef = 4V,
ADC clock = 200 kHz,
Temp = –40°C to +150°C
DNL 0.4 1.5 LSB
Gain error
Vcc = 4V, VRef = 4V,
ADC clock = 200 kHz,
Temp = –40°C to +150°C
–6.0 –2.5 +2.0 LSB
Offset error
Vcc = 4V, VRef = 4V,
ADC clock = 200 kHz,
Temp = –40°C to +150°C
–3.5 +1.5 +3.5 LSB
Ref voltage V
REF
2.56 AVCC V
